- Page 1 EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK Mounting and operating instructions...
-
Page 2: Table Of Contents
EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK Table of contents SAFETY AND PRECAUTIONS PRODUCT DESCRIPTION ARTICLE CODES INTENDED AREA OF USE TECHNICAL DATA STANDARDS WIRING AND CONNECTIONS OPERATIONAL DIAGRAMS MOUNTING INSTRUCTIONS IN STEPS VERIFICATION OF INSTALLATION INSTRUCTIONS OPERATING INSTRUCTIONS MODBUS REGISTER MAPS TRANSPORT AND STORAGE WARRANTY AND RESTRICTIONS MAINTENANCE... -
Page 3: Safety And Precautions
EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK SAFETY AND PRECAUTIONS Read all the information, the datasheet, mounting and operating instructions and study the wiring and connection diagram before working with the product. For personal and equipment safety, and for optimum product performance, make sure you entirely understand the contents before installing, using, or maintaining this product. -
Page 4: Product Description
CONTROLLER WITH TK PRODUCT DESCRIPTION The EVSS1 is an electronic speed controller which controls the speed of single- phase (230 VAC / 50—60 Hz) voltage controllable electric motors. It is equipped with Modbus RTU (RS485) communication, an alarm relay output and thermal contacts to provide overheating protection of motors with cut-out contacts. -
Page 5: Standards
EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK ■ Motor overheating indication ■ Enclosure: plastic R-ABS, UL94-V0; grey colour (RAL 7035) ■ Protection standard: IP54 (according to EN 60529) ■ Operating ambient conditions: temperature: -20—40 °C ► rel. humidity: < 95 % rH (non-condensing) ►... -
Page 6: Operational Diagrams
EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK OPERATIONAL DIAGRAMS Normal / Remote operating modes Ascending input mode Descending input mode U out , [%] U out , [%] Umax Umax Umax Umax range range Umin Umin Umin Umin range range 10 VDC Ai , 10 VDC... - Page 7 EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK Ascending input mode Descending input mode Uout, [%] Uout, [%] Umax Umax Umax Umax range range Umin Umin range Off level Off level Umin Umin range 10 VDC / t [s] 20 mA 0 VDC / t [s] 10 VDC /...
-
Page 8: Mounting Instructions In Steps
EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK MOUNTING INSTRUCTIONS IN STEPS Before you start mounting the EVSS controller read carefully “Safety and Precautions”. Choose a smooth surface for an installation location (a wall, panel and etc.). Follow these steps: Switch off the power supply. Open the enclosure cover and fix the unit to the wall or panel using the provided dowels and screws. - Page 9 EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK Select the required analog input type and mode, start mode and OFF level mode by the DIP switch on the board. (See Fig. 4 DIP switch settings.) Min. Max. level speed speed Fig. 4 DIP switch settings ON - Descending mode: Ascending / descending 10—0 VDC / 20—0 mA...
-
Page 10: Verification Of Installation Instructions
EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK Fig. 6 Max. speed trimmer Fig. 7 Min. speed trimmer Fig. 8 Off level trimmer Min. Max. Min. Max. Min. Max. level speed speed level speed speed level speed speed Close the enclosure and fix the cover. Switch on the power supply. -
Page 11: Operating Instructions
EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK ATTENTION The status of the LEDs can be checked only when the unit is energised. Take the relevant safety measures! OPERATING INSTRUCTIONS OPERATION MODES In Modbus mode you control the parameters: Umax, Umin, Kick start / Soft start, Off level enable / disable and Off level value through Modbus registers. -
Page 12: Modbus Register Maps
EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK MODBUS REGISTER MAPS MODBUS REGISTER MAPS INPUT REGISTERS Data type Description Data Values 0 VDC 100 = 10,0 VDC Analog input value depending on the selected analog Analog input level unsigned int. 0—100 input type. - Page 13 EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK HOLDING REGISTERS Data type Description Data Default Values Device slave address unsigned int. Modbus device address 1—247 9.600 19.200 Modbus baud rate unsigned int. Modbus communication baud rate 1—4 38.400 57.600 Modbus parity unsigned int.
- Page 14 EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK INPUT REGISTERS (See Table 1 Modbus register maps) The input registers are read-only. Table 1 shows how the data is organized in the input register sector. The measured data starts from address 1 (30001) and ends at address 14 (30014).
- Page 15 EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK the analog input signal is below the value of the OFF level (if enabled) or when the remote control input is disabled, the output voltage of the unregulated output L1 is 0 = OFF (0 VAC). Otherwise it is 1 = On (230 VAC). Input Register 13 (30013) shows the status of the alarm LED (Fig. 10).
-
Page 16: Transport And Storage
EVSS ELECTRONIC FAN SPEED CONTROLLER WITH TK Holding register 15 (40015) contains the OFF level state. The default value is ‘0’ (disabled). ‘1’ is for enabled. Holding register 16 (40016) defines the OFF level. This value depends on the selected analog input type and mode. The register values vary in the ranges of 0—40 (0— 4,0 VDC) for ascending voltage signal and 60—100 (6,0— 10,0 VDC) for descending voltage signal.
