Appendix B: F75111N I C DIO device
1-1 IO Device:F75111 under DOS
The Sample code source you can download from
Source file: F75111_Dos_Src.rar
Binary file: F75111_Dos_Bin.rar
USERNAME & PASSWORD: sf
How to use this Demo Application
1.Boot Ms-Dos Operating System
2.execute "75WDT.EXE" binary file
3.Input 1 to Enable WDT timer or input 0 to Disable it.
4.input numbers of second for chip countdown and Reset Computer
F75111 Layout Picture
2
http://tprd.info/lexwiki/index.php/IO_Device:F75111_under_DOS
76
