Lex Computech 2I385PW Manual page 46

Configure LVDS Panel Number as
The Panel resolution supported are below:
640 x 480 18bit
800 x 600 18bit
1024 x 768 18bit (default)
800 x 480 18bit
1024 x 600 18bit
1280 x 800 18bit
1366 x 768 18bit
800 x 600 24bit
1024 x 768 24bit
1280 x 800 24bit
1366 x 768 24bit
1280 x 1024 48bit
1440 x 900 48bit
1600 x 1200 48bit
1920 x 1080 48bit
Note: If no LVDS on this platform, this item will be inactive and change gray item.
Aperture Size
The optional settings are: 128MB, 256MB(default), 512MB.
IGD - DVMT Pre-Allocated
Use this item to select DVMT 5.0 pre-allocated (fixed) graphics memory size used by the
internal graphics device.
The optional settings are: 64(default)/96/128/160/192/224/256/288/320/352/384/416/448/480/512MB
IGD - DVMT Total Gfx Mem
Use this item to select DVMT 5.0 total graphics memory size used by the internal graphics device
The optional settings are:128M, 256M(default), MAX
42
