n Supplied Accessories
Microphone
Microphone hanger
and screw set
DC power cable Speaker*
Key cap
Mounting bracket Flat washers
Spring washers
Nuts
*Depending on version
• Function name stickers
Microphone
There are no names on the programmable function keys
hanger cable
since the functions can be freely assigned to these keys.
Attach the supplied function name stickers as below to the
appropriate keys for easy recognition of that key's assigned
function.
Then, protect the attached stickers from unsticking with the
Function name
supplied key cap as below.
stickers
KEY-STICKER
Bracket bolts
Mounting screws
(M5×12)
Self-tapping screws
(M5×16)
CONNECTION AND MAINTENANCE
3
Function name sticker
Key cap
