Schweitzer Engineering Laboratories SEL-311L Instruction Manual page 706

*default
Obj Var
2 1 Binary Input Change without Time
2 2* Binary Input Change with Time
2 3 Binary Input Change with Relative Time
10 0 Binary Output—All Variations
10 1 Binary Output
10 2* Binary Output Status
12 0 Control Block—All Variations
12 1 Control Relay Output Block
12 2 Pattern Control Block
12 3 Pattern Mask
20 0 Binary Counter—All Variations
20 1 32-Bit Binary Counter
20 2 16-Bit Binary Counter
20 3 32-Bit Delta Counter
20 4 16-Bit Delta Counter
20 5 32-Bit Binary Counter without Flag
20 6* 16-Bit Binary Counter without Flag
20 7 32-Bit Delta Counter without Flag
20 8 16-Bit Delta Counter without Flag
21 0 Frozen Counter—All Variations
21 1 32-Bit Frozen Counter
21 2 16-Bit Frozen Counter
21 3 32-Bit Frozen Delta Counter
21 4 16-Bit Frozen Delta Counter
21 5 32-Bit Frozen Counter with Time of Freeze
21 6 16-Bit Frozen Counter with Time of Freeze
21 7 32-Bit Frozen Delta Counter with Time of Freeze
21 8 16-Bit Frozen Delta Counter with Time of Freeze
21 9 32-Bit Frozen Counter without Flag
21 10 16-Bit Frozen Counter without Flag
21 11 32-Bit Frozen Delta Counter without Flag
21 12 16-Bit Frozen Delta Counter without Flag
22 0 Counter Change Event—All Variations
22 1 32-Bit Counter Change Event without Time
22 2* 16-Bit Counter Change Event without Time
22 3 32-Bit Delta Counter Change Event without Time
H-6
Object
Description
Distributed Network Protocol (DNP) 3.00 Level 2
SEL-311L Instruction Manual
Request Response
(supported) (may generate)
Func Qual Func
Codes Codes Codes
(dec) (hex) (dec)
1 6,7,8 129
1 6,7,8 129,130
1 6,7,8 129
1 0,1,6,7,8
1 0,1,6,7,8 129
3,4,5,6 17,28 129
1 0,1,6,7,8
1 0,1,6,7,8 129
1 0,1,6,7,8 129
1 6,7,8
1 6,7,8 129
1 6,7,8 129,130
Date Code 20010625
Qual
Codes
(hex)
17,28
17,28
17,28
0,1
echo of
request
0,1,7,8
0,1,7,8
17,28
17,28
