87L Channel X Configuration Settings
Channel X address check (Y, N)
If EADDCX = Y
Channel X transmit address (1–16)
Channel X receive address (1–16)
Continuous dropout alarm (1–1000 seconds)
Packets lost in last 10,000 (1–5000)
One-way channel delay alarm (1–24 ms)
If CHANX type is EIA-422
EIA-422 receive clock edge detect (R = Rising; F = Falling)
EIA-422 transmit clock edge detect (R = Rising; F = Falling)
If CHANX type is not EIA-422
Timing source (I = Internal; E = External)
87L Channel Y Configuration Settings
Channel Y address check (Y, N)
If EADDCY = Y
Channel Y transmit address (1–16)
Channel Y receive address (1–16)
Continuous dropout alarm (1–1000 seconds)
Packets lost in last 10,000 (1–5000)
One-way channel delay alarm (1–24 ms)
If CHANY type is EIA-422
EIA-422 receive clock edge detect (R = Rising; F = Falling)
EIA-422 transmit clock edge detect (R = Rising; F = Falling)
If CHANY type is not EIA-422
Timing source (I = Internal; E = External)
