Note: It is possible to disable the factory reset option of the OPN-2001 with the SDK (and
subsequently our Standard PC Demo Application). If this is disabled this feature will not work
until re-enabled.
Firmware
The main OS functions as a batch mode scanner and requires the use of the Companion Application.
The OS also supports the function of the USB-HID (keyboard) mode.

Loading Firmware

The Firmware of the OPN-2001 can be upgraded (or reloaded in the case of a corrupt firmware) with
the following instructions.
1. Download and install the
2. Download and install
3. Download the
4. Connect the OPN-2001 to the PC
5. Launch
6. In Appload select 'Settings' > 'Port' > 'Opticon USB Code Reader(1D) (COMx)'
7. In Appload select 'File' > 'Download' and browse to the firmware file (e.g. RBBV0140.hex)
and click 'open'
The download will take approximately 30 seconds at which time you will see the message
'Download successfully completed'
USB-HID
How to Configure the OPN2001 in HID Mode
Print the page linked
How to Switch between HID Mode and Classic Mode
Print the page linked
Scan the "Batch Mode" barcode to configure the OPN2001 in Classic Mode.
Scan the "Keyboard Mode" barcode to configure the OPN2001 in HID Mode.
About Keyboard Mode
USB-HID (keyboard) mode allows the scanner to function as a batch scanner when disconnected
from the computer and a real-time scanner when connected.
Real Time- To use the OPN2001 scanner as a real time scanner, configure it in HID mode, plug it
into the computer and scan barcodes.
Batch- When disconnected it will store barcodes. You can then bring it back to the PC, and plug it
in to retrieve the data. When the trigger is pressed the first time after reconnecting to a PC it will
transmit all data off of the unit and onto the PC wherever the cursor happens to be (Excel,
6 sur 13
USB Drivers
Appload
firmware for the OPN-2001
Appload
here and scan the Keyboard Mode barcode.
here .
.
.
.
