Initial Setup; Scan Barcodes - Opticon OPN-2001 Quick Start Manual

these are located in the

Initial Setup

You will only need to do this part once per computer.
1. Download the "PC USB Drivers Installer" from the
Run the installer you downloaded by double-clicking on it. Follow the prompts on your screen
until the installation is completed.
2. Download the OPN PC Companion Application which is also located in the
Downloads section
3. Open the compressed file, and run the OPN200X Setup.exe. Follow the instructions in the
wizard to install the software. When it is finished installing, the PC Companion Application
dialog will appear.
4. Plug the OPN-2001 into your computer. Windows will inform you that it has found new
hardware, and that it is installing the drivers for that hardware. Then you will see the status
indicator in the application window turn green. From the application window you can download
barcodes, change settings, or view and set the date and time on the device.

Scan Barcodes

Collecting data with the OPN-2001 is as simple as pointing and scanning. Scanning barcodes with
the big button or "trigger" will store barcodes, while scanning with the small button or "function" will
remove barcodes. Below are some tips about scanning and removing barcodes from the device.
When the OPN-2001 has a good scan, it will chime, the LED on the device will flash green, and
the laser will turn off.
When the OPN-2001 deletes a barcode, it will give a different chime than above, and it will flash
an Orange LED when it has a good scan.
Deleting the same barcode again when there are no more scans of it present will cause the
OPN-2001 to chime for about a second. The LED will also flash red.
Download From the OPN-2001
If you haven't done so yet, refer to the Initial Setup instructions above to get all the proper software
installed and ready. This part of the guide assumes that you have already successfully setup your
computer to communicate with the OPN-2001.
1. Plug the OPN-2001 into your computer.
2. Open the OPN-2001 PC Companion Application by navigating to the Start Menu shortcut you
created during the Initial Setup. This is usually in Opticon/OPN200X/OPN200X, and it will
have an icon that looks like one of our OPN2001's.
3. Double-check that the "Status" light is green.
4. Check the box next to "Save to file" if you would like your barcodes to be saved to your
computer each time you select "Get Barcodes." By default, the barcodes will be stored in the
Documents folder on your computer. To change this, click on the ellipsis(...) button and
choose where you would like your barcodes saved.
5. Click "Get barcodes" to download the barcodes that you just scanned. Double-check that they
got saved to your file before proceeding.
2 sur 13
Downloads section of this page.
of this page.
Driver Downloads section of this page.
