Advantech ASMB-913I Startup Manual

ASMB-913I Intel Xeon® E5-2600 v3 series EATX Server
Board with 16 DDR4 DIMM, 3 PCIe x16, PME support, 4 GbE
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 ASMB-913I Startup Manual
• 1 Driver CD (user's manual is included)
• 2 Serial ATA HDD data cables
• 2 Serial ATA HDD power cables
• 2 CPU power cables (8P)
• 1 I/O port bracket
• 1 Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the ASMB-913I series Rev. A1
Part No. 2001913I10
Print in China
Specifications
Standard SBC Functions
• CPU: Dual LGA2011-R3 Intel Xeon® E5-2600v3 series
• BIOS: AMI 128 Mb SPI BIOS
• Chipset: Intel® C612 PCH
• System Memory: 16* DDR4 REG 1600/1866/2133
DIMM, Max. 512 GB
Note:
• SATA Interface: 8 SATA3 6 Gb/s ports Intel Matrix
Storage (for Windows only) (SATA0-SATA5 and sSATA0-
sSATA1 Supports software RAID 0, 1, 10 & 5)
• Serial ports: Two serial ports, only support RS-232
• Keyboard/mouse connector (KBMS2): Supports the
standard PS/2 keyboard and mouse via PS/2 cable
• Watchdog timer: 255 level timer intervals
• USB port: Supports up to three USB 2.0 ports (1*Type-
A) and six USB 3.0 ports (4 ports from on-board 20pin
header)

VGA Interface

• Chipset: Aspeed AST2400/1400
• Display Memory: 64 MB
• Resolution: Supports VGA up to resolution 1920 x 1200
@ 60 Hz refresh rate

Ethernet Interface

• Interface: 10/100/1000 Mbps
• Controller: LLAN1_BMC:Intel I210 (only ASMB-913I
sku support BMC); LAN2: Intel I210; LAN3/4: Intel I210
(ASMB- 913I sku only)
Mechanical and Enviroment
• Dimensions (L x W): 330 x 304 mm (13" x 12")
• Power supply voltage: +3.3 V, +5 V, ±12 V, +5 Vsb
• Power consumption (mainboard only, excluding IO
device): Max. load: +3.3 V @ 1.40 A, +5 V@ 0.50 A, +12
V@ 23.20 A,+5 Vsb@ 0.09 A, -12 V@ 0.05 A
• Operating temperature: 0 ~ 40° C (depending on CPU)
• Weight: 1.7 kg (weight of board)
1st Edition
May 2015
Due to the inherent limitations of PC architecture,
the system may not fully detect 512 GB RAM
when 512 GB RAM is installed.
ASMB-913I Startup Manual 1
