Instructions and Parts List
3M-Matic
Accuglide
NPH Taping Heads
2 Inch
Type 21700
Serial #:
Important Safety Information
BEFORE INSTALLING OR OPERATING THIS EQUIPMENT
Read, understand and follow all safety and operating instructions.
Spare Parts
It is recommended you immediately order the spare parts listed in the "Spare
Parts/Service Information" section. These parts are expected to wear through
normal use, and should be kept on hand to minimize production delays.
3M-Matic
Accuglide NPH - 2 Inch Taping Head - Type 21700
™
Page i
™
TM
For reference, record machine serial number here.
NA - ENG
June 2017
