Instructions and Parts List

3M-Matic

Accuglide

NPH 2 Inch

Taping Heads

Type 11200

Serial No._____________________________________

For reference, record taping head(s) serial number(s) here.

3M Industrial Adhesives and Tapes

3M Center, Building 220-5E-06

St. Paul, MN 55144-1000

™

Important Safety

Information

BEFORE INSTALLING

OR OPERATING THIS

EQUIPMENT

Read, understand, and

follow all safety and

operating instructions.

Spare Parts

It is recommended you

immediately order the

spare parts listed in the

"Spare Parts/Service

Information" section.

These parts are expected

to wear through normal

use, and should be kept

on hand to minimize

production delays.

AccuGlide

™

is a Trademark of

3M, St. Paul, MN 55144-1000

Printed in U.S.A.

Table of Contents

Need help?

Do you have a question about the 3M-Matic Accuglide NPH 11200 and is the answer not in the manual?

Questions and answers

Summary of Contents for 3M 3M-Matic Accuglide NPH 11200

Page 1 For reference, record taping head(s) serial number(s) here. on hand to minimize production delays. AccuGlide ™ is a Trademark of 3M Industrial Adhesives and Tapes 3M, St. Paul, MN 55144-1000 3M Center, Building 220-5E-06 Printed in U.S.A. St. Paul, MN 55144-1000 © 3M 2017 44-0009-2122-9 (C030817-NA)
Page 3: Replacement Parts And Service Information
5365 East Center Dr. N.E. 1-800-344-9883 e-mail: CSPD-CSR@combi.com Canton, OH 44721 www.combi.com Identiﬁ cation Plate For Industrial Use Only 3M Industrial Adhesives and Tapes ™ ™ 3M-Matic and Scotch 3M Center, Building 220-5E-06 are Trademarks of St. Paul, MN 55144-1000 3M St.
Page 5 3M-Matic and Scotch ™ ™ 3M Industrial Adhesives and Tapes are Trademarks of 3M Center, Building 220-5E-06 3M, St. Paul, MN 55144-1000 St. Paul, MN 55144-1000 Printed in U.S.A.
Page 6 THIS PAGE IS BLANK...
Page 7: Table Of Contents
Instruction Manual NPH 2 Inch Upper and Lower Taping Heads Type 11200 Table of Contents Page Replacement Parts and Service Information .................... i - ii Table of Contents............................Equipment Warranty and Limited Remedy ....................Intended Use ............................Taping Head Contents / How to Use Manual.................... Important Safeguards ..........................
Page 8: Equipment Warranty And Limited Remedy
If any part is defective within this warranty period, your exclusive remedy and 3M’s and seller’s sole obligation shall be, at 3M’s option, to repair or replace the part. 3M must receive actual notice of any alleged defect within a reasonable time after it is discovered, but in no event shall 3M have any obligation under this warranty unless it receives such notice within ﬁ...
Page 9: Intended Use
3M-Matic™ case sealers. This includes replacement of other types of taping, gluing or stapling heads in existing case sealing machines. The NPH 2 inch Upper and Lower Taping Heads have been designed and tested for use with Scotch ®...
Page 10 THIS PAGE IS BLANK...
Page 11: Taping Head Contents / How To Use Manual
(ELV), a glossary with a deﬁ nition of symbols, plus a parts list of the 3M-Matic™ NPH 2 inch 3M Industrial Adhesives and Tapes Di- vision 3M Center, Bldg. 220-5E-06 St. Paul, MN 55144-1000 (USA) Edition December 2014 / Copyright 3M 2014.
Page 12: Important Safeguards
Important Safeguards This safety alert symbol identiﬁ es CAUTION important safety messages in this manual. • To reduce the risk associated with muscle READ AND UNDERSTAND THEM BEFORE strain: INSTALLING OR OPERATING THIS EQUIPMENT. − Use proper body mechanics when removing or installing taping heads that are Explanation of Signal Word Consequences moderately heavy or may be considered...
Page 13 See "Replacement Parts Illustrations and Parts Lists" for label part numbers. 78-8137-6723-9 Upper Taping Head 78-8137-7091-0 Lower Taping Head NPH Taping Head Type 11200 Made in Italy 78-8070-1336-8 78-8070-1335-0 Figure 1-1 Replacement Labels/3M Part Numbers 2014 December NPH 2" - NA...
Page 14: Speciﬁ Cations
Speciﬁ cations Tape: For use with Scotch pressure-sensitive ﬁ lm box sealing tapes. ® Tape Width: 36mm [1 1/2 inches] minimum to 48mm [2 inches] maximum. Tape Roll Diameter: Up to 405mm [16 inches] maximum on a 76.2mm [3 inch] diameter core. (Accommodates all system roll lengths of Scotch ﬁ...
Page 15: Dimensional Drawing
Speciﬁ cations 79.50 mm [3.13 in.] 375.0 mm [14.76 in.] 406.4 mm [16.00 in.] 350.0 mm Maximum [13.78 in.] Roll Diameter M6 Mounting Holes 152.0 mm [5.98 in.] 18.0 mm 12.5 mm [.71 in.] 6.4 mm [.49 in.] [.25 in.] Max.
Page 16: Installation
The taping heads must be evident, ﬁ le a damage claim immediately with the completely staggered so only one tape seal is transportation company and also notify your 3M being applied at one time. Representative. 4. Mounting studs are provided with the taping...
Page 17: Operation
Operation Figure 3-1 Taping Head Tape Supply Roll Components/ Threading Diagram - Tape Drum Upper Head (Left Side View) Tape Adhesive Side One-Way Tension Roller Cut Off Spring Link Arm Tension Wrap Roller Bufﬁ ng Arm Wrap Roller Mounting Block Mounting Block Tape Support Assembly Tape Cut Off Blade...
Page 18: Tape Loading - Upper Taping Head
Operation (continued) WARNING • To reduce the risk associated with shear, pinch, and entanglement hazards: − Turn air and electrical supplies off on associated equipment before performing any adjustments, maintenance, or servicing the machine or taping heads. − Never attempt to work on the taping heads or load tape when the box drive system is running. •...
Page 19 Operation (continued) Figure 3-4 Place tape roll on tape drum to dispense tape with adhesive side forward. Seat tape roll fully against back ﬂ ange of drum. Adhere tape lead end to tape as shown. WARNING • To reduce the risk associated with sharp blade hazards: Keep hands and ﬁ...
Page 20: Maintenance
Maintenance WARNING • To reduce the risk associated with shear, pinch, and entanglement hazards: − Turn air and electrical supplies off on associated equipment before performing any adjustments, maintenance, or servicing the taping heads − Never attempt to work on the taping head or load tape while the box drive system is running •...
Page 21: Cleaning
Maintenance (continued) WARNING • To reduce the risk associated with shear, pinch, and entanglement hazards: − Turn air and electrical supplies off on associated equipment before performing any adjustments, maintenance, or servicing the taping heads. − Never attempt to work on the taping head or load tape while the box drive system is running. •...
Page 22: Adjustments
Adjustments WARNING • To reduce the risk associated with shear, pinch, and entanglement hazards: Turn air and electrical supplies off associated equipment before perform- ing any adjustments, maintenance, or servicing the machine or taping heads. Never attempt to work on the taping head or load tape while the box drive Figure 5-1 Tape Latch Alignment system is running.
Page 23: Applying Mechanism Spring
Adjustments (continued) WARNING • To reduce risk associated with shear, pinch, and entanglement hazards: - Turn air and electrical supplies off associated equipment before performing any adjustments, maintenance, or servicing the machine or taping heads. - Never attempt to work on the taping head or load tape while the box drive system is running.
Page 24 Troubleshooting Troubleshooting Guide Cause Correction Problem The tape is threaded incorrectly The tape must go around the wrap The tape leg on the front of the roller before going around the case is too long one-way tension roller The tape tension is too low Adjust the one-way tension roller Tape tracks to one side or drags Adjust the tape web alignments...
Page 25: Troubleshooting Guide
Troubleshooting (continued) Troubleshooting Guide Cause Correction Problem There is excess tension on the Adjust the one-way tension roller Tape is tabbing on the trailing leg tape drum assembly and/or the and/or the tape drum assembly on the back of the box one-way tension roller assembly Rollers in the tape path do not Clean adhesive deposits from...
Page 26: Spare Parts/Service Information
Spare Parts / Service Information Recommended Spare Parts Listed below are tools that are included with tape head. These parts should be kept in a convenient location to assist in routine maintenance and set-up of the tape head. NPH 2" Upper Taping Head Qty.
Page 27: Replacement Parts And Service
Not all the parts listed are normally stocked items. Some parts or assemblies shown Important – are available only on a special order basis. Contact 3M/Tape Dispenser Parts to conﬁ rm item availability. 2014 December NPH 2" - NA...
Page 28 THIS PAGE IS BLANK...
Page 29 NPH 2" Figure 15610 Upper - Figure 15608 Lower - Figure 15708 Upper - Figure 15606 Lower - Figure 15706 Upper - Figure 15607 Lower - Figure 15707 Upper - Figure 15605 Figure 15609 Lower - Figure 15709 Taping Head Assembies - AccuGlide ™...
Page 30 NPH 2" Full View Figure 15605 - Upper Taping Head / Applying Assembly NPH 2" - NA 2014 December...
Page 31 NPH 2" Figure 15605 - Upper Taping Head / Applying Assembly Ref. No. 3M Part No. Description 15605-1 26-1001-9843-6 Screw - Flat Soc Hd, M6 X 16 15605-2 26-1003-5829-5 Screw - Hex Hd, M6 X 12 15605-3 78-8113-7030-9 Spring - Torsion Blade Guard...
Page 32 NPH 2" Full View Figure 15606 - Upper Taping Head / Bufﬁ ng Assembly 2014 December NPH 2" - NA...
Page 33 NPH 2" Figure 15606 - Upper Taping Head / Bufﬁ ng Assembly Ref. No. 3M Part No. Description 15606-1 26-1001-9843-6 Screw - Flat Soc Hd, M6 X 16 15606-2 78-8076-4503-7 Screw - Hex Hd, M6-1.00 X 12mm Lg., Zinc Plated...
Page 34 NPH 2" Full View Figure 15607 - Upper Taping Head / Blade Guard Assembly NPH 2" - NA 2014 December...
Page 35 NPH 2" Figure 15607 - Upper Taping Head / Blade Guard Assembly Ref. No. 3M Part No. Description 15607-1 78-8656-4005-2 Ring - Retaining 5mm, Waldes Tru-Arc #5133-25 15607-2 26-0001-5862-1 Screw - Flat Soc Hd, M5 X 12 15607-3 26-1001-9843-6 Screw - Flat Soc Hd, M6 X 16...
Page 36 NPH 2" Version 1 Full Assembly = Version 2 Full Assembly = "Little David" Figure 15608 - Upper Taping Head / Frame Assembly 2014 December NPH 2" - NA...
Page 37 NPH 2" Figure 15608 - Upper Taping Head / Frame Assembly Ref. No. 3M Part No. Description Version 1 and Version 2: 15608-1 26-0001-5862-1 Screw - Flat Soc Hd, M5 X 12 15608-2 26-1001-9843-6 Screw - Flat Soc Hd, M6 X 16...
Page 38 NPH 2" Figure 15609 - Upper and Lower Taping Head / Arm Assembly NPH 2" - NA 2014 December...
Page 39 NPH 2" Figure 15609 - Upper and Lower Taping Head / Arm Assembly Ref. No. 3M Part No. Description 15609-1 78-8137-5731-3 Arm - Link 15609-2 78-8137-7054-8 Bolt - Shoulder M6 - 8 Dia X 10L 15609-3 78-8137-5733-9 Bearing - Flanged Acetal 8 X 10 X 5L...
Page 40 NPH 2" Figure 15610 - Upper and Lower Taping Head / Taping Head Assembly 2014 December NPH 2" - NA...
Page 41 NPH 2" Figure 15610 - Upper and Lower Taping Head / Taping Head Assembly Ref. No. 3M Part No. Description 15610-1 26-1005-5316-8 Screw - Flat Hd Hex Dr, M5 X 16 15610-2 78-8137-7056-3 Arm - Tape Drum 15610-3 78-8137-5722-2 Tape Drum Assembly - 2 Inch...
Page 42 NPH 2" Full View Figure 15709 - Lower Taping Head / Applying Arm Assembly NPH 2" - NA 2014 December...
Page 43 NPH 2" Figure 15709 - Lower Taping Head / Applying Arm Assembly Ref. No. 3M Part No. Description 15709-1 26-1001-9843-6 Screw - Flat Soc Hd, M6 X 16 15709-2 26-1003-5829-5 Screw - Hex Hd, M6 X 12 15709-3 78-8137-8943-1 Spring - Torsion Blade Guard...
Page 44 NPH 2" Full View Figure 15706 - Lower Taping Head / Bufﬁ ng Arm Assembly NPH 2" - NA 2014 December...
Page 45 NPH 2" Figure 15706 - Lower Taping Head / Bufﬁ ng Arm Assembly Ref. No. 3M Part No. Description 15706-1 26-1001-9843-6 Screw - Flat Soc Hd, M6 X 16 15706-2 78-8076-4503-7 Screw - Hex Hd, M6-1.00 X 12mm Lg., Zinc Plated...
Page 46 NPH 2" Full View Figure 15707 - Lower Taping Head / Blade Guard Assembly NPH 2" - NA 2014 December...
Page 47 NPH 2" Figure 15707 - Lower Taping Head / Blade Guard Assembly Ref. No. 3M Part No. Description 15707-1 78-8656-4005-2 Ring - Retaining 5mm, Waldes Tru-Arc #5133-25 15707-2 26-0001-5862-1 Screw - Flat Soc Hd, M5 X 12 15707-3 26-1001-9843-6 Screw - Flat Soc Hd, M6 X 16...
Page 48 NPH 2" Version 1 Full Assembly = Version 2 Full Assembly = "Little David" Figure 15708 - Lower Taping Head / Frame Assembly 2014 December NPH 2" - NA...
Page 49 NPH 2" Figure 15708 - Lower Taping Head / Frame Assembly Ref. No. 3M Part No. Description Version 1 and Version 2: 15708-1 26-1001-5862-1 Screw - Flat Soc Hd, M5 X 12 15708-2 26-1001-9843-6 Screw - Flat Soc Hd, M6 X 16...
Page 50 THIS PAGE IS BLANK...
