Operation and Maintenance Manual
This Operations Manual is in reference to the
Security Engineered Machinery Paper Shredders referenced below:
SERIES
STRIP CUT
2226
2226S
2331
244
344
3130
3140
3140S
266
5140
5141S
1324
1324S
For sales, service, parts, and customer support, contact us:
5 Walkup Drive • Westborough, MA 01581
1-508-366-1488 • Toll Free US 1-800-225-9293
REFERENCE SEM MODEL NUMBERS
CROSS CUT
4 mm
4 mm x 40
mm
2226P
2331P
3130P
3140P
266P
5141P
1323P
POP-0024 Rev. 0 | Created 05/30/2019
SECURITY ENGINEERED MACHINERY
info@semshred.com
www.semshred.com
1
CROSS CUT
HIGH
2 mm x 15
SECURITY
CROSS CUT
mm
. 8 mm x 5
mm
2226PSP
2226CC/3
2331PSP
244/4
344
3130PSP
3140PSP
266PSP
266/4
5141PSP
5140C/4
1324PSP
1324CC/3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SEM 2226 Series
Summary of Contents for SEM 2226 Series
- Page 1 Operation and Maintenance Manual This Operations Manual is in reference to the Security Engineered Machinery Paper Shredders referenced below: REFERENCE SEM MODEL NUMBERS SERIES STRIP CUT CROSS CUT CROSS CUT HIGH 4 mm 4 mm x 40 2 mm x 15...
-
Page 2: Safety Precautions
DEFINITION OF NORMAL USE: 1. This paper shredder is suitable for the destruction of paper. 2. The cutting shafts, which are made of special hardened steel, are unaffected by small quantities of paper clips and staples. This does not apply to paper shredders with a particle size of 0.8 mm x 12 mm or smaller, which do not accept staples or paper clips. - Page 3 2 seconds. Green LED control light is off. There will be no power consumption when machine is off. Within 30 minutes the paper shredder uses the following wattage: Model Wattage Use 244/4 1,595 1,595 2226 Series 1,595 2331 Series 1,595 3130 Series 1,595 3140 Series 1,595...
-
Page 4: Installation
INSTALLATION REFERENCE MODELS 244/4, 344, 2226 SERIES, 2331 SERIES, 3130 SERIES and 3140 SERIES Open the door. Place the machine into the top of the cabinet. We recommend that two people set up this unit! Beware of fingers. Risk of injury. - Page 5 INSTALLING THE OILER REFERENCE MODELS 244/4, 344, 2226 SERIES, 2331 SERIES, 3130 SERIES, 3140 SERIES, 266 SERIES, and 5140 SERIES Take the oiler holder out of the cabinet and • hook it into the side of the cabinet (A). Remove the lid from the oiler (B).
-
Page 6: Operation
OPERATION Press the rocker switch (1.) : green light is on, the machine is now ready for operation. Starts automatically when paper is inserted. Automatic standby that switches off after 30 minutes. The machine can be switched off at any time by pressing the switch for 2 seconds. Green LED control light is off. - Page 7 Operation - Continued Empty the bag when Stops automatically “bag full” indicator when plastic bag is illuminates. FULL. Shake the container several times to ensure a clean removal. If required: Press the Stops automatically rocker switch "R" and if too much paper is remove paper.
-
Page 8: System Alert
(in effect creating an “oil sandwich”) and simply feed the paper into the system. The oil from the sheets will then be dispersed onto the cutting head. For added convenience, SEM offers “lubricant sheets” as an option and are noted in the accessories page in this operator’s manual. - Page 9 Troubleshooting: Machine will not start Is the machine plugged in? Is the rocker switch pressed? The green light rocker switch is ON? (1.). Insert paper (2.). Feed the paper into the center of the feed opening? (photo cell) (A) Is the door open? Is the plastic bag full? Is the safety flap open?
- Page 10 Remove plug. Clean the machine cool down. photo cell (A) with a • Symbols and "R" flash small brush. alternatively. • Symbol lights green, machine is ready for operation. Still having trouble: Call SEM tech support at 800-225-9293 or email info@semshred.com...
-
Page 11: Lubricating Oil
Since there are different waste collection bins and accessories for each specific model, to insure that you are requesting the appropriate item, please contact SEM Customer Care at 800-225-9293 or service@semshred.com. Please have the system model number and serial number available. The SEM Custiomer Care dept will be able to provide the appropriate item number and cost. -
Page 12: Technical Information
TECHNICAL INFORMATION Do not shred paper clips and/or CD/DVD with any of the HIGH SECURITY MODELS as noted below. Strip Cut and/or Cross Cut (4mm x 40 mm) systems can destroy staples and paper clips as well as CD/DVD. NOTE: It is very important to oil frequently when shredding CD/DVDs in any of the strip cut and/or 4 x 40 mm Cross Cut systems. -
Page 13: Sound Levels
The exact technical specifications can be found on the technical specifications sticker on the machine. To claim under guarantee, the machine must still carry its original identification label. Subject to alterations without notice. MFG Model SEM MODEL Particle Size (dB)A (dB)A... -
Page 14: Ec Declaration Of Conformity
UL-IDENT. Nr. 2026-2 CCC 244/4, 344 Series ID Nr. 11260501 ID Nr. 10260501 2326 S; 2326 C; 2326 CC; 2326 CCC 2226 Series ID Nr. 11260401 ID Nr. 10260401 2331 S; 2331 C 2331 Series ID Nr. 11310401 ID Nr. 10310401 2339 S;... - Page 15 Security Engineered Machinery For sales, service, parts and customer support, contact us: service@SEMSHRED.com www.semshred.com 1-508-366-1488 1-800-225-9293 5 Walkup Drive, Westborough, Massachusetts 01581 Follow us on social media: Facebook: https://www.facebook.com/semshred Twitter: https://twitter.com/semsecure Linkedin: https://www.linkedin.com/company/security-engineeredmachinery Youtube: https://www.youtube.com/user/datadestruction...
