Contactless Card Reader (Optional)
The built-in Infinea BluePad tag/card reader is used for NFC payments.
To Use the Contactless Card Reader:
1.
Place the RFID tag/card over the receiver/transmitter as indicated by the NFC label on the front
of the BluePad unit.
2.
Press the RFID card reading button on the application. The data is sent from Infinea BluePad
reader to the iOS.
Note: See NFC LED Indicator table below for an explanation of the status indicators.
Do not remove the card from the receiver/transmitter until the transaction is completed.
Removing the card too quickly may void the transaction.
Infinea® BluePad User Manual
UM-00014 Rev A
Figure 5: Contactless Card (RFID) Reader
Page 34 of 47
