SYSTEM MODE—Settings
Display fields and additional menu options available through the Settings menu option are shown.
Descriptions and examples of each screen are provided.
Field
Label
Select from the following setting options:
RS SPEED:
Default RS232 serial port communication
parameters:
Select from the following setting options:
USB MODE:
Default USB VC serial port communication
parameters:
Infinea® BluePad User Manual
UM-00014 Rev A
Description
• 9600
• 19200
• 36400
• 57600
• 115200 (Default)
• 115200bps
• 8bit
• 2stop bit
• No parity
• HOST (for connecting with iOS
device)
• DEVICE
• DISABLE
• 115200bps
• 8bit
• 1 stop bit
• No parity
Example
settings
rs speed 115200
usb mode host
bluetooth
settings
rs speed 115200
usb mode host
bluetooth
