Summary of Contents for Elation Artiste Monet

  • Page 1 user manual...
  • Page 2 +31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu Elation Professional Mexico | AV Santa Ana 30 | Parque Industrial Lerma, Lerma, Mexico 52000 +52 (728) 282-7070 D O C U M E N T V E R S I O N...

  • Page 3: Table Of Contents

    C O N T E N T S General Information Limited Warranty (USA Only) Safety Guidelines Maintenance Guidelines Fixture Overview Colors, Gobos, Animation SpectraColor Guide Custom Gobos GOBO Installation Installation Guidelines System Menu DMX Channel Functions and Values Error Codes Specifications Optional Accessories...

  • Page 4: General Information

    BOX CONTENTS Omega Brackets (x2) Neutrik powerCON TRUE1 Power Cable CUSTOMER SUPPORT Contact ELATION Service for any product related service and support needs. Also visit forums.elationlighting.com with questions, comments or suggestions. ELATION SERVICE USA - Monday - Friday 8:00am to 4:30pm PST 323-582-3322 | Fax 323-832-9142 | support@elationlighting.com...

  • Page 5: Limited Warranty (Usa Only)

    No accessories should be shipped with the product. If any accessories are shipped with the product, Elation Professional shall have no liability what so ever for loss and/or or damage to any such accessories, nor for the safe return thereof. C. This warranty is void if the product serial number and/or labels are altered or removed;...

  • Page 6: Safety Guidelines

    This fixture is a sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. Elation Professional is not responsible for injury and/or damages resulting from the misuse of this fixture due to the disregard of the information printed in this manual.
  • Page 7 S A F E T Y G U I D E L I N E S 94 lbs. (42.6kg) RISK GROUP 3 - RISK OF EXPOSURE TO ULTRAVIOLET UV RADIATION! FIXTURE EMITS HIGH INTENSITY WAVELENGTH OF ULTRAVIOLET UV LIGHT FROM THE UV COLOR FILTER. WEAR PROPER EYE AND SKIN PROTECTION.

  • Page 8: Maintenance Guidelines

    Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized Elation service technician. Should you need any spare parts, please order genuine parts from your local Elation dealer.

  • Page 9: Fixture Overview

    F I X T U R E O V E R V I E W 1. Lens 2. Tilt Lock 3. System Menu Display 4. MODE/ESC Button 5. LEFT Button 6. ENTER Button 7. DOWN Button 8. RIGHT Button 9. UP Button 10.

  • Page 10: Colors, Gobos, Animation

    C O L O R S , G O B O S , A N I M A T I O N COLOR FLAGS CYAN MAGENTA YELLOW C.T.O. GREEN BLUE COLOR WHEEL GREEN HIGH CRI ORANGE BLUE INTERCHANGEABLE-ROTATING GLASS GOBO WHEEL 1 STATIC-FIXED GLASS GOBO WHEEL 2 ANIMATION WHEEL...

  • Page 11: Spectracolor Guide

    S P E C T R A C O L O R G U I D E The Monet’s innovative SpectraColor system combines the established and well known CMY / CTO controls with three Pure RGB flags that are seamlessly adjustable. These flags greatly enhance the possible color range of the Monet for some truly outstanding colors that can be difficult to achieve with only CMY controls.

  • Page 12: Custom Gobos

    Extended testing of custom gobo designs is highly recommended prior to use. Contact ELATION SERVICE for further information. ELATION SERVICE USA - Monday - Friday 8:00am to 4:30pm PST 323-582-3322 | Fax 323-832-9142 | support@elationlighting.com...

  • Page 13: Gobo Installation

    G O B O I N S T A L L A T I O N Tilt Lock Pan Lock 1. Before removing covers, place fixture on a stable flat surface in an INDOOR DUST FREE location. Ensure moving head is locked into a neutral upright position with both PAN and TILT locks engaged. 2.
  • Page 14 G O B O I N S T A L L A T I O N 3. The GOBO Wheel module is secured to the fixture frame rail with (4x) sliding slotted brackets. To remove the module, loosen the (4x) Philips-head screws just enough (do not remove them) to allow the slotted brackets to slide down.
  • Page 15 G O B O I N S T A L L A T I O N 5. Locate the 9-pin connector and carefully unplug it from its socket. DO NOT USE FORCE TO REMOVE! 6. Carefully grip the GOBO Wheel module and slid it out just enough to reveal two more wire connectors. 7.
  • Page 16 G O B O I N S T A L L A T I O N 8. Slide the GOBO Wheel module completely out and away from the fixture. Carefully place the module on a stable flat surface in an INDOOR DUST FREE location. 9.
  • Page 17 G O B O I N S T A L L A T I O N 10. Locate the tab of the retaining spring. Using a precision pick (or similar tool), carefully press the retaining spring inward to relieve the tension. Remove the retaining spring and carefully separate the GOBO from the GOBO Holder.

  • Page 18: Installation Guidelines

    I N S T A L L A T I O N G U I D E L I N E S FLAMMABLE MATERIAL WARNING Keep fixture minimum 5.0 feet (1.5m) away from flammable materials and/or pyrotechnics. ELECTRICAL CONNECTIONS A qualified electrician should be used for all electrical connections and/or installations. USE CAUTION WHEN POWER LINKING OTHER MODEL FIXTURES AS THE POWER CONSUMPTION OF OTHER MODEL FIXTURES MAY EXCEED THE MAX POWER OUTPUT ON THIS FIXTURE.
  • Page 19 I N S T A L L A T I O N G U I D E L I N E S OMEGA BRACKETS INSTALLATION Insert the Omega Brackets into the matching holes on the bottom of the fixture. Secure the Omega Brackets to the fixture by turning each quick-lock fastener ¼...
  • Page 20 LEDs. This issue is not specific only to ELATION lighting fixtures, it is a common issue with lighting fixtures from all manufacturers. Although there is no true way to fully prevent this issue from happening, the guidelines below can prevent any potential damage from occurring if followed.

  • Page 21: System Menu

    S Y S T E M M E N U The fixture includes an easy to navigate system menu. The control panel (see image below) located on the front of the fixture, provides access to the main system menu and is where all necessary system adjustments are made to the fixture.
  • Page 22 ELATION ARTISTE MONET™ - S Y S T E M M E N U Supports Software Versions: ≥ 1.3.3 Features subject to change without notice. *Rotation direction (Clockwise/Counterclockwise) and control of effects depends on head orientation and Pan/Tilt settings. MAIN MENU...
  • Page 23 ELATION ARTISTE MONET™ - S Y S T E M M E N U Supports Software Versions: ≥ 1.3.3 Features subject to change without notice. *Rotation direction (Clockwise/Counterclockwise) and control of effects depends on head orientation and Pan/Tilt settings. MAIN MENU...
  • Page 24 S Y S T E M M E N U PERSONALITY - Status Settings - Address Via DMX When ON, define the desired DMX address via an external controller. NOTE: This process assumes the fixture DMX address is set to 001. If fixture DMX address is not at 001, you must adjust the channel numbers accordingly in order for this feature to work.
  • Page 25 FIXTURE SOFTWARE CAN NOT BE DOWNGRADED! DOWNLOAD FIXTURE SOFTWARE TO PC ONLY! (NO MAC SUPPORT) PLEASE CONTACT ELATION SERVICE FOR FURTHER INFORMATION. 1. Copy fixture software update file from a PC computer to a compatible USB flash drive. Make sure only the fixture software update file is stored on the USB flash drive.
  • Page 26 S Y S T E M M E N U EFFECT ADJUST – Calibration ONLY QUALIFIED TECHNICIANS SHOULD PERFORM THIS FUNCTION! This function allows small adjustments to be made to the Pan, Tilt, and Zoom movements to compensate for ware or in the event a sensor has been knocked slightly out of place. Because improper use of this function can result in undesired operation this function has been password protected.
  • Page 27 S Y S T E M M E N U EDIT PROGRAM – Record Controller – Working with Built-In Program [continued] To start an Auto Program, proceed as follows: 1. Slave Setting Select “Function Mode”. Press ENTER to confirm. Select “Set to Slave”. Press ENTER to confirm.
  • Page 28 S Y S T E M M E N U EDIT PROGRAM – Record Controller – Working with Built-In Program [continued] 5. Automatic Scene Recording Select “Edit Program”. Press ENTER to confirm. Select “Edit Scenes”. Select desired scene numbers. A maximum of 250 scenes can be programmed. Press ENTER to confirm.

  • Page 29: Dmx Channel Functions And Values

    D M X C H A N N E L F U N C T I O N S A N D V A L U E S ELATION ARTISTE MONET™ DMX Channel Values / Functions (67 Total DMX Channels) Supports Software Versions: ≥...
  • Page 30 Hold Standard Extended Value Function Default Snap Time COLOR WHEEL 0-19 Open 20-37 38-55 Green 56-73 74-91 High CRI 92-109 Orange 110-127 Medium Blue 128-189 Color Scroll CW FAST to SLOW 190-193 NO Rotation 194-255 Color Scroll CCW SLOW to FAST COLOR WHEEL FINE 0-255 Fine Control of Color Wheel Position...
  • Page 31 Hold Standard Extended Value Function Default Snap Time FIXED GOBOS [GOBO WHEEL 2] Open 10-19 Gobo 1 20-29 Gobo 2 30-39 Gobo 3 40-49 Gobo 4 50-59 Gobo 5 60-69 Gobo 6 70-77 Gobo 7 78-93 Gobo 1 Shake SLOW to FAST 94-109 Gobo 2 Shake SLOW to FAST 110-125...
  • Page 32 Hold Standard Extended Value Function Default Snap Time ROTATING PRISM, PRISM INDEXING 0-127 Prism Indexing 128-189 Prism Rotation CW FAST to SLOW 190-193 NO Rotation 194-255 Prism Rotation CCW SLOW to FAST ROTATING PRISM, PRISM INDEXING FINE 0-255 Fine Control of Prism Indexing FOCUS 0-255 Focus Adjustment from NEAR to FAR...
  • Page 33 Hold Standard Extended Value Function Default Snap Time DIM MODES 0-20 Standard 21-40 Stage 41-60 61-80 Architectural 81-100 Theatre 101-120 Stage 2 DIMMER DELAY TIME 0.1s 0.2s 0.3s 0.4s 0.5s 0.6s 0.7s 0.8s 0.9s 1.0s 1.5s 2.0s 3.0s 4.0s 5.0s 6.0s 7.0s 8.0s...
  • Page 34 Hold Standard Extended Value Function Default Snap Time IRIS 0-191 MAX Diameter to MIN Diameter 192-223 Pulse Closing FAST to SLOW 224-255 Pulse Opening SLOW to FAST IRIS FINE 0-255 Fine Control of Iris FROST Open to LIGHT Frost 0-127 128-255 Open to WASH Frost ANIMATION WHEEL...
  • Page 35 Hold Standard Extended Value Function Default Snap Time SPEED of CMY & Color Macro 0-255 Speed MAX to MIN COLOR MACROS - CMY & Color Wheel 0-31 32-39 Macro1 40-47 Macro2 48-55 Macro3 56-63 Macro4 64-71 Macro5 72-79 Macro6 80-87 Macro7 88-95 Macro8...
  • Page 36 Hold Standard Extended Value Function Default Snap Time BLADE 1A 0 -255 Open to Close BLADE 1A FINE 0 -255 Open to Close FINE BLADE 1B 0 -255 Open to Close BLADE 1B FINE 0 -255 Open to Close FINE BLADE 2A 0 -255 Open to Close...
  • Page 37 Hold Standard Extended Value Function Default Snap Time FRAMING MACROS 8-15 Macro1 16-23 Macro2 24-31 Macro3 32-39 Macro4 40-47 Macro5 48-55 Macro6 56-63 Macro7 64-71 Macro8 72-79 Macro9 80-87 Macro10 88-95 Macro11 96-103 Macro12 104-111 Macro13 112-119 Macro14 120-127 Macro15 128-135 Macro16 136-143...
  • Page 38 Hold Standard Extended Value Function Default Snap Time CONTROL 0-19 Color Change Normal 20-29 Color Change to Any Position 30-39 Color & Gobo Change to Any Position 40-59 Fan Mode Low 60-69 Fan Mode High 70-79 Fan Mode Auto (Default) 80-84 All Motor Reset 85-87...
  • Page 39 Hold Standard Extended Value Function Default Snap Time 1200 1210 1220 1230 1240 1250 1260 1270 1280 1290 1300 1310 1320 1330 1340 1350 1360 1370 1380 1390 1400 1410 1420 1430 1440 1450 1460 1470 1480 1490 1500 2500 4000 5000 6000...
  • Page 40 Hold Standard Extended Value Function Default Snap Time 169-180 Idle 181-190 Pan Tilt Smooth (default) 191-200 Pan Tilt Fast 201-210 Dimmer Curve Linear (default) 211-220 Dimmer Curve Square 221-230 Dimmer Curve Inverse Square 231-240 Dimmer Curve S-Curve Internal Program 1 (Scene 1-8) Internal Program 2 (Scene 9 -16) Internal Program 3 (Scene17-24) Internal Program 4 (Scene 25-32)

  • Page 41: Error Codes

    E R R O R C O D E S When power is applied, the unit will automatically enter a “Reset/Test” mode. This mode brings all the internal motors to a home position. If there is an internal problem with one or more of the motors an error code will flash in the display in the form of “XXer”...

  • Page 42: Specifications

    S P E C I F I C A T I O N S SOURCE 950W 6,500K Bright White LED Engine 30,000 Hour Average LED Life* *May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming. EFFECTS Motorized Zoom (large 160mm front lens) 4 Rotating Full Blackout Framing Blades...

  • Page 43: Optional Accessories

    DIMENSIONAL DRAWINGS Specifications and improvements in the design of this unit and this manual are subject to change without notice.
  • Page 44 O P T I O N A L A C C E S S O R I E S ORDER CODE ITEM TRIGGER CLAMP Heavy Duty Wrap Around Hook Style Clamp AC5PDMX5PRO 5 ft. (1.5m) 5pin PRO DMX Cable CAT6PRO5 5 ft.
  • Page 45 FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC RADIO FREQUENCY INTERFERENCE WARNINGS &...
