S P E C T R A L I N K Q U I C K N E T W O R K C O N N E C T ( Q N C ) G U I D E
Under the Wi-Fi Menu, you should complete the following configurations:
a. Enabled: Yes
b. DHCP: Enabled
c. SSID: {Put the name of your wireless network SSID}
d. Security: Choose as per customer's configuration: WPA2-PSK, WPA2-Enterprise, etc.
For example:
• If you choose WPA2-PSK above, Click on WPA2-PSK, then, you enter the paraphrase.
• If you choose WPA2-Enterprise, click on WPA2-Enterprise, then data-fill other options as desired.
Here is the example of how you enter passphrase with WPA2-PSK security.
You need to go to the security type under the Wi-Fi menu. In the Wi-Fi menu, the security types are:
• WEP
• WPA2-PSK
• WPA2-Enterprise
Click on the "WPA2-PSK" as above. Then, you can enter the passphrase.
It says:
• PSK Type: Passphrase
• Passphrase: *******
You click on the Passphrase, and you will be able to enter the new passphrase.
e. Radio: Choose either 2.4 Hz or 5.0 Hz and the same MUST be enabled.
Radio ► Regulatory domain: 01 – for North America (SHOULD NOT BE 'None')

Troubleshooting the QNC Bug

Some of the QNC versions have been found to contain a corrupt configuration file; thanks to the same, the wireless
settings could not be downloaded from the QNC to the phone.
Spectralink is going to correct this error in the next release. However, this error can be manually corrected by the
following procedure:
1. Verification of the issue:
a. Connect QNC with your PC as usual. Type the following in the browser:
You will see the file 00000000.cfg is with 0 byte. This is the issue and it should have 281 bytes.
http://192.168.1.1/usb/ftp/
