Summary of Contents for LSIS SV-iS7 Series

  • Page 2 SV-iS7 Pulse Encoder Interface Option Module Before using the product, thank you for using our SV-iS7 Pulse Encoder Interface Option Module. Safety Instruction  To prevent injury and danger in advance for safe and correct use of the product, be sure to follow the Safety Instructions. ...
  • Page 3: Table Of Contents

    SV-iS7 Pulse Encoder Interface Option Module INDEX Introduction ............................4 Chapter 1. 1.1 What This Product Contains........................4 1.2 Option Module ............................4 1.3 Installment ..............................5 Terminal Block Specification ....................... 6 Chapter 2. 2.1 Name and Description ..........................6 2.2 Power Specification for Terminal Block ......................
  • Page 4: Chapter 1. Introduction

    SV-iS7 Pulse Encoder Interface Option Module Chapter 1. Introduction 1.1 What This Product Contains This option module is delivered in a package that also contains the following items: 1) Pulse Encoder Interface Module : 1ea 2) User’s Manual : 1ea 3) Screw (M3) : 1ea 1.2 Option Module Encoder Type...
  • Page 5: Installment

    SV-iS7 Pulse Encoder Interface Option Module 1.3 Installment The pictures describe the installation for pulse encoder interface option module on iS7 inverter body. Before the installment of pulse After the installment of pulse encoder interface module on encoder interface module on inverter body inverter body...
  • Page 6: Chapter 2. Terminal Block Specification

    SV-iS7 Pulse Encoder Interface Option Module Chapter 2. Terminal Block Specification 2.1 Name and Description Signal Symbol Name Description +5V Encoder Line Drive power +12V Encoder Line Drive/ Encoder Power Open Collector power +15V Encoder Open Collector power Ground Encoder power ground Connects the shielded wire of Shield encoder signal cable...
  • Page 7: The Wiring Example Of Pulse Encoder Option Module

    SV-iS7 Pulse Encoder Interface Option Module 2.3 The Wiring Example of Pulse Encoder Option Module 2.1.1 Using Pull Up/Down resistor It is described the example that power and resistor are connected to RTA and RTB output of Pulse encoder interface option module. - Power : 24V, Resistor: 1/2W 4.7KΩ...
  • Page 8 SV-iS7 Pulse Encoder Interface Option Module 2.1.2 Using PLC Consider the input circuit before wiring since the output of option module is open collector output. The wiring when signal is inputted from option module to High-speed counter of PLC (manufactured by LS Industrial Systems) is as shown below.
  • Page 9: Chapter 3. Encoder Wiring And Switch Setting

    SV-iS7 Pulse Encoder Interface Option Module Chapter 3. Encoder Wiring and Switch Setting 3.1 +12/15V Complementary or Open Collector wire +12/15V Open Collector (OC) 3.2 +5V Line Drive +5V Line Drive (LD) 3.3 +12V Line Drive +12V Line Drive (LD)
  • Page 10 SV-iS7 Pulse Encoder Interface Option Module Warning Do not change the switch setting of encoder type in operation. It can affect to the system since the trip is occurred by changing the setting. Please set the switch setting correctly to encoder type and operate the inverter.
  • Page 11: Chapter 4. Precaution When Encoder Wiring

    SV-iS7 Pulse Encoder Interface Option Module Chapter 4. Precaution when Encoder Wiring 4.1 Check the Axis Connection between the Motor and Encoder in Installment ① Encoder must be installed the place where the revolution speed is synchronized with the motor axis. (Example) The axis of motor for load, The axis of motor at opposite side for traction machine ②...
  • Page 12 SV-iS7 Pulse Encoder Interface Option Module Warranty Installation Maker LS Industrial Systems Co., Ltd. (Start-up) Date Model No. SV-iS7 Warranty Period Name Customer Address Information Tel. Name Sales Office Address (Distributor) Tel. Warranty period is 12 months after installation or 18 months after manufactured when the installation date is unidentified.
  • Page 13 SV-iS7 Pulse Encoder Interface Option Module...
  • Page 14 SV-iS7 Pulse Encoder Interface Option Module 제품을 사용하기 전에 먼저 저희 Pulse Encoder Interface Module 을 사용하여 주셔서 감사합니다. 안전상의 주의사항  안전상의 주의사항은 사고나 위험을 사전에 예방하여 제품을 안전하고 올바르게 사용하기 위한 것이므로 반 드시 지켜주십시오.  주의사항은 ‘경고’와 ‘주의’의 두 가지로 구분되어 있으며 ‘경고’와 ‘주의’의 의미는 다음과 같습 니다.
  • Page 15: 소개

    SV-iS7 Pulse Encoder Interface Option Module 1. 소개 1.1 제품 구성품 이 옵션보드 제품은 아래와 같이 구성되어 있습니다. 1) Pulse Encoder Interface Module : 1 대 2) 매뉴얼 : 1 부 3) 고정용 Screw (M3) : 1 개 1.2 옵션 외관 Encoder Type 선택...
  • Page 16: 설치

    SV-iS7 Pulse Encoder Interface Option Module 1.3 설치 Pulse Encoder Interface Module 을 IS7 본체에 설치하는 사진입니다. Encoder Interface Module 본체 장착 전 Encoder Interface Module 본체 장착 후...
  • Page 17: 단자대 규격

    SV-iS7 Pulse Encoder Interface Option Module 2. 단자대 규격 2.1 단자대 명칭 및 설명 분류 단자 기호 단자 명칭 단자 설명 +5V Encoder 라인 드라이브 전원 +12V Encoder 라인 드라이브/ Encoder 전원 오픈 콜렉터 전원 출력 +15V Encoder 오픈 콜렉터 전원 전원...
  • Page 18: Pulse Encoder 옵션보드 결선 예

    SV-iS7 Pulse Encoder Interface Option Module 2.3 Pulse Encoder 옵션보드 결선 예 2.3.1 Pull Up/Down 저항 연결 사용시 인버터 Pulse Encoder Interface Module 의 RTA, RTB 출력에 전원과 Pull Up/Down 저항을 연결하여 사용하는 경우의 전원 및 저항 사용 예 입니다. 전원...
  • Page 19: 12/15V Complementary 또는 오픈 콜렉터

    SV-iS7 Pulse Encoder Interface Option Module 3. 엔코더 결선 및 스위치 설정 방법 3.1 +12/15V Complementary 또는 오픈 콜렉터 +12/15V Open Collector (OC) 3.2 +5V 라인 드라이브 +5V Line Drive (LD) 3.3 +12V 라인 드라이브 +12V Line Drive (LD)
  • Page 20: Pulse Encoder Module 과 Encoder 결선 시 주의 사항

    SV-iS7 Pulse Encoder Interface Option Module 주 의  인버터 운전 중에 Encoder 타입 전환 스위치 설정을 변경하지 마십시오. 운전 중 변경하면 트립이 발생하여 시스템에 영향을 미칠 수 있습니다. 따라서 반드시 운전을 시작하기 전에 Encoder 타입에 맞는 스위치 설정 선택을 정확하게 설정하신...
  • Page 21 SV-iS7 Pulse Encoder Interface Option Module 품 질 보 증 서 제품명 LS 산전 통신옵션카드 설치 일자 모델명 SV-iS7 Pulse Encoder 보증 기간 성 명 고 객 주 소 전 화 성 명 판매점 주 소 전 화 알아두기 본 제품은 LS 산전 기술진의 엄격한 품질관리 및 검사과정을 거쳐서 만들어진 제품입 니다.
