Specifications - ATD Tools ATD-7328 Owner's Manual

Model Capacity
ATD-7328 22 Ton
Handle
Handle Position
Release
Adapter Holder
Handle Sleeve
Figure 1 - Typical Truck Jack Nomenclature

SPECIFICATIONS

Jack Size (L x W)
Height
22-7/8" x 12-1/2" 8-1/4"
(release valve)
3
Min. Max.
Height
22"
(With adapter)
Handle Knob
Air Supply Inlet,
1/4 NPT
Lift Control
Valve
Adapter, 2-1/2"
Saddle
Extension Screw
Oil Filler
Screw
Carrying
Handle
Hyd. Extension
Range Screw
4-5/8" 3-7/8"
