Fireplace Installation

CAUTION: Ensure installation
does not allow fireplace to be
in direct contact with building
vapor barrier or insulation and
meets all local building code.
!
NOTE: A dedicated, properly
fused 15 Amp circuit is
recommended, rated for 120V.
A dedicated circuit will be
required if, after installation,
the circuit breaker trips or
fuse blows on a regular basis
when the heater is operating.
Additional appliances on the
same circuit may exceed the
current rating of the circuit
breaker.
WARNING: Construction
and wiring must comply with
local building codes and other
applicable regulations to
reduce the risk of fire, electric
shock and injury to persons.
WARNING: To reduce the risk
of fire, electric shock or injury to
persons, always use a licensed
electrician.
WARNING: To reduce the
risk of fire, do not store or use
gasoline or other flammable
vapors or liquids in the vicinity
of the heater.
www.dimplex.com
1. Select a location that is not
susceptible to moisture and is
away from drapes, furniture and
high traffic.
2. Unpack the fireplace and
hardware from the box.
!
NOTE: Leave the front glass
and partially reflective glass,
safely, in the box until the time
you are ready to install it.
3. Store the fireplace in a safe, dry
and dust free location until you
are ready to install the fireplace.

Framing

CAUTION: Two people will be
required for various steps of this
procedure.
The design of this unit allows
three options for installation:
partial recess, flush mounted or
sub-surface mounted.
CAUTION: Sub-surface
mounting should be limited
to ½ in. (13 mm) to ensure
adequate air flow of heated air
out of the firebox area.
