Dmi/Opi Configuration - Avalue Technology EMX-Q170KP User Manual

Item
Primary Display
Active LVDS
CH7511 EDID Panel Option

3.6.3.1.2 DMI/OPI Configuration

Option
Auto[Default]
IGFX
PEG
Disabled
Enabled[Default]
1024x768 24/1[Default]
800x600 18/1
1024x768 18/1
1366x768 18/1
1024x600 18/1
1280x800 18/1
1920x1200 24/2
1920x1080 18/2
1280x1024 24/2
1440x900 18/2
1600x1200 24/2
1366x768 24/1
1920x1080 24/2
1680x1050 24/2
Description
Select which of IGFX/PEG/PCI Graphics device
should be Primary Display Or select SG for
Switchable Gfx.
Active on-board eDP to LVDS Converter.
Set which panel resolution EDID reported by
CH7511.
EMX-Q170KP User's Manual 59
