INSTALLING THE DEVICE VIA
ETHERNET CONNECTIONS
1. Connect a straight-through Ethernet cable to the blue
back of the NF18ACV and then connect the other end to your upstream
gateway device, for example an FTTP gateway or HFC cable modem.
2. Connect the supplied RJ45
Ethernet ports (1-4) on the back of the NF18ACV to your computer.
3. Connect the included power adapter to the
and then plug it into an available wall socket. Press the
to power the router on. The Power light illuminates in red. When the
NF18ACV has finished booting up, the Power light turns green.
Ethernet cable from one of the yellow
Power jack of the NF18ACV
WAN port on the
ON/OFF button
