PRE-REQUISITES

If you are using a voice service on
the same line as the DSL service,
you will need a DSL line filter for
each handset or back-to-base
home alarm system on the line. If
you have a Naked DSL service,
line filters are not required.
4
INSTALLING THE DEVICE
VIA DSL CONNECTIONS
1. Connect the supplied RJ11 cable to the "modem" port of your DSL line
filter and then connect the other end to the
NF18ACV. Connect the DSL line filter (not included) to the wall socket
and then connect your handset to the "phone" port of the filter. If you
have a Naked DSL service, simply connect the included RJ11 cable
from the DSL port of the NF18ACV to the wall socket. If you have a
VoIP service, connect your handset to one of the
the back of the router.
2. Connect the supplied RJ45 Ethernet cable from one of the yellow
Ethernet
ports (1-4) on the back of the NF18ACV to your computer.
3. Connect the included power adapter to the
and then plug it into an available wall socket. Press the
to power the router on. The Power light illuminates in red. When the
NF18ACV has finished booting up, the Power light turns green.
DSL port on the back of the
Telephone ports on
Power jack of the NF18ACV
ON/OFF button
