NetComm NF18ACV - VDSL

Step 1

Connect your nbn™ equipment and modem using the setup guide provided for your

technology type. If you have not completed this, please refer back to the nbn™set up

guides.

Step 2

Ensure the modem is powered on. Using a pin, reset the modem by pressing and

holding the reset button on the modem until all the lights go off.

Step 3

Using your own device (computer, laptop, tablet or smartphone), connect to the

modem using one of the two options shown below: Ethernet cable directly to the

Ethernet port or WiFi.

Ethernet

Connect the Ethernet cable (this is usually yellow, blue, grey or white) as shown below

from the Ethernet port (LAN port) on the modem to the Ethernet port on your computer

or laptop.

Page 1 NetComm NF18ACV - VDSL Step 1 Connect your nbn™ equipment and modem using the setup guide provided for your technology type. If you have not completed this, please refer back to the nbn™set up guides. Step 2 Ensure the modem is powered on. Using a pin, reset the modem by pressing and holding the reset button on the modem until all the lights go off.
Page 2 WiFi Using the wireless security card from your modem (usually located on the bottom of the modem), connect to the wireless (WiFi) network using the security code shown. Step 4 Open a web browser - E.g. Google Chrome, Firefox, Internet Explorer. Enter the following into the URL address bar: 192.168.20.1 You may see a login page and if the details are not already prefilled, use the below...
Page 3 Step 6 Select Create New Write FLIP-NBN in the Description. Select Internet Service as VDSL. Select Connection Type as PPPoE. Enter the Username and Password that is provided by Flip. 802.1P and VLAN is by default (-1), please keep them unchanged. Then, click Apply.
Page 4 Step 7 Congratulations- Your BYO modem set up should now be complete! Please note you may need to wait a few minutes for the settings to apply and/or may also need to reboot/powercycle your modem (turn oﬀ and on again) if it does not occur automatically.
