Step 1
M5*20
Before assembly
No.
1
2
3
4
Environmentally friendly rubber pillar washer
5
The Y axis is separated from the hole position, the
front section is long, and the rear section is short.
Long
Front X axis
Name
X axis aluminum profile 472mm
Y axis aluminum profile 422mm
End cap
M5*20 socket hexagon screw
After assembly
Short
Qty.
2
2
4
4
12
Rear X axis
