- Page 1 ® Eaton 93PM Remote Monitoring Device Installation and Operation Manual...
- Page 2 NEC are registered trademarks of National Fire Protection Association, Inc. All other trademarks are property of their respective companies. ©Copyright 2015 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton Corporation.
-
Page 3: Table Of Contents
GETTING HELP ................... . . Eaton 93PM Remote Monitoring Device (RMD) Installation and Operation Manual P-164000516—Rev 1... - Page 4 Eaton 93PM Remote Monitoring Device ........
-
Page 5: Introduction
It is not a full remote display and it does not offer any control or operation capability. The RMD is housed in small plastic case with a separate battery charger cord that can be placed on a desk or wall mounted. -
Page 6: Figure 3. Rmd Wall Mounting Bracket
Introduction Locking Latch Bottom Support Rail Charger Connector Access Figure 3. RMD Wall Mounting Bracket Eaton 93PM Remote Monitoring Device (RMD) Installation and Operation Manual P-164000516—Rev 1... -
Page 7: Installation
Gateway Minislot (PXGMS) card must be installed in the UPS to use the RMD. Install the PXGMS card into the UPS Minislot. Refer to the applicable Eaton 93PM UPS Installation and Operation manual (see For More Information section) for the UPS Minislot location and wiring access information and to the Eaton®... -
Page 8: Rmd Installation
Mount the RMD in the bracket by placing the bottom edge of the RMD into the bracket bottom rail support and then snapping the top edge under the locking latch (see Figure 3). -
Page 9: Figure 4. Location Of Rmd Components
Installation Power Pushbutton 4.3“ Display Screen Front View Ethernet 10/100 (RJ45) Back View Audible Alarm End View Speaker/Buzzer Side View Micro USB Figure 4. Location of RMD Components Eaton 93PM Remote Monitoring Device (RMD) Installation and Operation Manual P-164000516—Rev 1... -
Page 10: Operation
The components identified and described in this section are used to connect and operate the RMD. 4.3” Display Screen – shows UPS status Power Pushbutton – turns the RMD on (press and hold for 3 seconds) and off (press and hold for 11 seconds) and is used to silence the audible alarm Audible Alarm –... -
Page 11: Powering The Rmd
RMP may not establish communication. To turn the RMD on press and hold the power pushbutton on the front of the RMD (see Figure 4) for three seconds. The RMD should start with the Eaton logo being displayed. Then the power pushbutton on the front of the RMD will illuminate green and the screen shown in Figure 5 should be displayed. -
Page 12: System Events
ACT is blinking green. If the Activity LED on the RMD is not blinking green, check that the network cable is the correct type and securely connected to the Ethernet 10/100 port for both the PXGMS card and the RMD. -
Page 13: Figure 7. Normal Screen
The information area will display the remaining backup time in minutes and seconds. Both the Input and Battery icons are illuminated yellow due to loss of input power while the UPS is on battery. Figure 8. On Battery Screen Eaton 93PM Remote Monitoring Device (RMD) Installation and Operation Manual P-164000516—Rev 1... -
Page 14: Figure 9. On Bypass Screen
All alarms are accompanied by an audible signal. To silence the audible signal, press the power button momentarily (see Figure 4). The Alarm status indicator may be illuminated along with other indicators. Figure 10. Fault Condition Screen Eaton 93PM Remote Monitoring Device (RMD) Installation and Operation Manual P-164000516—Rev 1... -
Page 15: For More Information
For More Information For More Information Refer to the Eaton 93PM UPS (20–50 kW, 480V – 50 kW Frame) Installation and Operation Manual, the Eaton 93PM UPS (20–100 kW, 480V – 100 kW Frame) Installation and Operation Manual, the Eaton 93PM UPS (20–150 kW, 480V –... - Page 16 This page intentionally left blank. Eaton 93PM Remote Monitoring Device (RMD) Installation and Operation Manual P-164000516—Rev 1...
