Maxcess SE-22 Installation Instructions

SE-22 SENSOR

General information

NOTES:
1) All dimensions in brackets are millimeters [mm].
2) The standard position of the receptacle is on the rear of
the sensor at the solar cell end as shown in the
illustration above. It can be moved to either side of the
sensor as follows:
(a) Remove the sensor cover plate and gasket adjacent
to the receptacle.
(b) Remove the hole plug from the position where
receptacle is to be placed.
(c) Unscrew the receptacle while holding the retaining
nut on the inside of the sensor body.
05/11/2007
(d) Move

SPECIFICATIONS:

Product Weights
SE–22 Sensor
With M–17 Sensor Mounting
With M–18 Sensor Mounting
With M–1935 Sensor Mounting
Maximum Operating
Ambient Temperature
Voltage Required for
Operation
© 2007 Fife Corporation. All rights reserved.
Page 1 of 2
SE-22 INFRARED SENSOR
INSTALLATION INSTRUCTIONS
receptacle to desired location, refasten
the receptacle, and reassemble the senso
Table 1
SE-22 WITH OPTIONAL M-17
OR M-18 SENSOR MOUNTING
SQUARE BAR
SENSOR
A MAXIMUM
MOUNTING
SIZE LENGTH
0.75 60.00
M-17
[19] [1524]
1.00 86.00
M-18
[25] [2184]
r.
10 oz (281 g)
13 oz (368 g)
14 oz (397 g)
64 oz (1825 g)
140° F (60° C)
10 to 15 VDC
B C D
2.69 1.50 0.63
[68] [38] [16]
2.82 2.00 0.75
[71] [51] [19]
Figure Sheet 1-663-A
