Table Of Contents - Daikin FTE09JV2S Service Manual

Si04-960
1. Removal of Air Filter................................................................................2
2. Removal of Front Grille ...........................................................................4
3. Removal of Horizontal Blades / Vertical Blades......................................6
4. Removal of Electrical Box / PCB / Swing Motor......................................8
5. Removal of Indoor Heat Exchanger ......................................................13
6. Removal of Drain Plug (Right / Left Replacement) ...............................16
7. Removal of Fan Rotor / Fan Motor........................................................17
Note:
Removal Procedure

Table of Contents

The illustrations may be slightly different depending on the model.
1
