DAIKIN
DAIKIN ROOM AIR CONDITIONER
OPERATION MANUAL
( �
MODELS:
F/GTL28UV16W1
F/GTL35UV16W1, F/GTL35UV16W3
F/GTL50UV16U3, F/GTL50UV16V3
F/GTL50UV16V7, F/GTL50UV16V5
F/GTE60UV16U2
F/GTQ60UV16U5
F/GTL50UV16U2, F/GTL50UV16V2
F/GTQ50UV16U2, F/GTQ50UV16V2
FTQ50UV16V3
l
D
�a�
""1j[r>
�7c:
��
�
I
3P719813-10 M
3P719813-10 M
Advertisement
Table of Contents
Related Manuals for Daikin FTL28UV16W1
Summary of Contents for Daikin FTL28UV16W1
- Page 1 DAIKIN 3P719813-10 M DAIKIN ROOM AIR CONDITIONER OPERATION MANUAL ( � �a� ""1j[r> �7c: �� � MODELS: F/GTL28UV16W1 F/GTL35UV16W1, F/GTL35UV16W3 F/GTL50UV16U3, F/GTL50UV16V3 F/GTL50UV16V7, F/GTL50UV16V5 F/GTE60UV16U2 F/GTQ60UV16U5 F/GTL50UV16U2, F/GTL50UV16V2 F/GTQ50UV16U2, F/GTQ50UV16V2 3P719813-10 M FTQ50UV16V3...
-
Page 2: Safety Precautions
Safety Precautions Safety Precautions ,&_CAUTION • Do not use the air conditioner for purposes other than • Keep this manual where the user can easily find it. those for which it is intended. Do not use the air • Read the precautions in this manual carefully before operating the unit. conditioner for cooling precision instruments, food, plants, •... -
Page 3: Name Of Parts
Read before Operation Name of Parts ■ Indoor Unit 1. Front panel 2.Air inlet 3. Air filter 4. Accessory filter 5. Model name plate 6. Indoor temperature sensor: • Detects the air temperature around the unit. 7.Display 8. Air outlet 9. - Page 4 ■ Read before Operation Name of Parts ■ Remote Controller 1. Signal transmitter: • It send signals to the indoor unit. 2. Display (LCD): • It displays the current setting. (In this illustration, each section is shown with its display on for the r-H>-- - -3 7---..
-
Page 5: Preparation Before Operation
Read before Operation Preparation before Operation CAUTION----------------- Incorrect handling of batteries can result in injury from battery leakage, rupturing or heating, or lead to equipment failure. Please observe the following precautions and use safely. • If the solution from the batteries should get in the eyes, do not rub the eyes. Instead, immediately flush the eyes with tap water and seek the attention of a medical professional. -
Page 6: Dry · Cool · Fan Operation
■ ■ ■ Operation DRY · COOL · FAN Operation The air conditioner operates with the operation mode of your choice. From the next time on, the air conditioner will operate with the same operation mode. ■ ■ To start operation To stop operation 1. - Page 7 Operation Adjusting the Airflow Rate/ SMELL PROOF Operation Adjusting the airflow rate You can adjust the airflow rate to increase your comfort. ■ To change the airflow rate setting Press [+ FAN). • Each pressing of (otFANJ advances the airflow rate setting in sequence. •...
-
Page 8: To Cancel The Child Lock
Operation Adjusting Airflow Direction/CHILD LOCK operation You can adjust the airflow direction to increase your comfort. & CAUTION------------------ • Always use a remote controller to adjust the angles of the flaps. Moving the flaps forcibly by hand may cause a malfunction. •... - Page 9 Operation COANDA/POWER CHILL & ECONO Operation ECONO Operation COANDA Operation ECONO operation enables efficient operation Directs airflow upward.This function prevents air by limiting the maximum power consumption. from blowing directly at users. This function is useful to prevent the circuit ■...
- Page 10 Operation TIMER/GOOD SLEEP Operations TIMER Operation GOOD SLEEP Operations Timer functions are useful for automatically ■ To use GOOD SLEEP OFF TIMER operation. switching the air conditioner on or off in the GOOOS�EP . ress C!L) urmg L operation. morning or at night. You can also use the ON □...
-
Page 11: Care And Cleaning
Care Care and Cleaning &CAUTION • Before cleaning, be sure to stop the operation and turn off the circuit breaker. • Do not touch the aluminium fins of the indoor unit. If you touch those parts, this may cause an injury. •... - Page 12 Care Care and Cleaning I Air filter I • � c� • 1. Pull out the air filters. • Open the front panel. • Push the filter tab at the centre of each air filter a little upwards, then pull it down. 2.
- Page 13 Care Care and Cleaning Accessory filter I Filter type: Titanium apatite deodorizing air-purifying filter/ Air-purifying filter/ Anti microbial filter. [Maintenance] The accessory filters can be renewed by washing them with water once every 6 months. We recommend replacing them once every 3 years. 1.
-
Page 14: Troubleshooting
Troubleshooting Troubleshooting These cases are not problems. The following cases are not air conditioner troubles but have some reasons. You may just continue using it. Case Explanation Operation does not start soon. • This is to protect the air conditioner. •... - Page 15 Troubleshooting Troubleshooting Case Explanation The indoor unit gives out • The room odour absorbed in the unit is discharged with the airflow. We recommend odour. you to have the indoor unit cleaned. Please consult your service centre. Remote controller does not No remote controller signals are displayed.
- Page 16 ■ Troubleshooting Troubleshooting Call your service centre immediately. & WARNING--------------- ■ when an abnormality (such as a burning smell} occurs, stop operation and turn off the circuit breaker. Continued operation in an abnormal condition may result in problems, electric shock or fire. Consult the service centre where you bought the air conditioner.
- Page 17 • A short beep indicates non-corresponding codes. • To cancel the code display, hold down [CANCEL) for about 5 seconds. The code display also cancels itself if the button is not pressed for 1 minute. DAIKIN INDUSTRIES, LTD. Head office: Osaka Umeda Twin Towers South...
- Page 21 39719813-10 M DAIKIN ROOM AIR CONDITIONER INSTALLATION MANUAL ;i; J MODELS: F/GTL28UV16W1 F/GTL35UV16W1, F/GTL35UV16W3 F/GTL50UV16U3, F/GTL50UV16V3 F/GTL50UV16V7, F/GTL50UV16V5 F/GTE60UV16U2 F/GTQ60UV16U5 F/GTL50UV16U2, F/GTL50UV16V2 F/GTQ50UV16U2, F/GTQ50UV16V2 3P719813-10 M FTQ50UV16V3...
- Page 22 SAFETY PRECAUTIONS • The precautions described herein are classified as WARNING and CAUTION. They both contain important information regarding safety. Be sure to observe all precautions without fail. • Meaning of WARNING and CAUTION notices � WARNING Failure to follow these instructions properly may result in personal injury or loss of life. �...
-
Page 23: Precautions For Selecting A Location
Accessories ® ~ ® ITEM ITEM QTY. Remarks QTY. Remarks ® Mounting plate ® Remote controller holder fixing screw (M3 x 20L @ MountinQ plate fixinQ screw (M4 x 25L) CO 4-Core wire (3. 7M) 517• © Wireless Remote Controller (8) Tiewrao @ Dry battery (AAA) ®... -
Page 24: Indoor Unit
INDOOR UNIT INSTALLING THE MOUNTING PLATE • The mounting plate should be installed on a wall which can support the weight of the indoor unit. 1) Temporarily secure the mounting plate to the wall, make sure that the panel is completely level, and mark the boring points on the wall. -
Page 25: Installing The Indoor Unit
INDOOR UNIT INSTALLING THE INDOOR UNIT ( Right-Side, Right-Back or Right-Bottom Piping) Open the front panel, open the Front grille (If Required), then open the service lid.(Refer to Installation Tips.) @Mounti n g plate Shape the refrigerant pipes. Refr i gerant p i pes Pass the drain hose and refrigerant pipes through the wall hole. -
Page 26: Drain Piping
INDOOR UNIT WIRING 1) Strip wire ends (15mm). Terminal block 2) Match wire colours with terminal numbers on indoor and outdoor unit's terminal blocks and firmly screw wires to the corresponding terminals with the screw. 3) Connect the earth wires to the corresponding terminals. Attach the earth wire so that it is not connected to the fan motor connector. - Page 27 BINDING OF INSULATION PIPE 1. The slit direction should be upward. Sectional view 2. It should be sealed with vinyl tape In!!� without any gap. Heatlnsulationpipee,;m,r 3. Do not over tighten with vinyl tape. Communicalioollire , .. n"::l. orion .111,botrom. ) �...
-
Page 28: Indoor/Outdoor Unit Installation Diagram
INDOOR/OUTDOOR UNIT INSTALLATION DIAGRAM • The mounting plate should be installed on a wall which can support the weight of the indoor unit. r--.,. @Mountlngplatefixlng' screw M4x2SL(7r,os.) @rillcunli1gpl ala flxlngocrewM4x25L(Jpcs.) For type CD®®@ (Refer table no. 2) For type@ (Refer table no. 3) Note: Before installation, mounting plate size &... -
Page 29: Installation Tips
■ ■ ■ ■ ■ INSTALLATION TIPS Installing and Removing the indoor unit. � CAUTION---------- • Installation method 1> Push up. Be sure to wear protection gloves. Hook the claws of the bottom frame to the mounting plate. If the claws are difficult to hook, remove the front grille. •... -
Page 30: Installing The Outdoor Unit
OUTDOOR UNIT INSTALLING THE OUTDOOR UNIT • When installing the outdoor unit, refer to and the "Precautions for Selecting a Location" "Outdoor Unit Installation Diagram". i'..111 FLARING THE PIPE END WARNING Incomplete flaring may result refrigerant gas leakage. c"' '"'""• at ��... -
Page 31: Purging Air And Checking Gas Leakage
OUTDOOR UNIT PURGING AIR AND CHECKING GAS LEAKAGE � WARNING ------------------------ • Do not mix any substance other than the specified refrigerant (R32) into the refrigeration cycle. • When refrigerant gas leaks occur, ventilate the room as soon and as much as possible. •... -
Page 32: Pump Down Operation
TRAIL OPERATION AND TESTING 1. Trial operation and testing • Check that the inter-unit wire is correctly connected. • Trial operation should be carried out in COOL operation. 1-1 Measure the supply voltage and make sure that it is within the specified range. 1-2 Select the lowest programmable temperature. - Page 33 210, 1st FLOOR, OKHLA INDUSTRIAL AREA, PHASE 3, DELHI-110020 Meaning of E-waste under E-Waste (Management) Rules,2022 (E-waste Rules) -Waste electrical and electronic equipment, whole or in part of reject from their manufacturing and repair process, which are intended to be discarded. Our product is RoHS compliant.
