DAIKIN ROOM AIR CONDITIONER

OPERATION MANUAL

MODELS
FTXS09HVJU
FTXS12HVJU

Advertisement

Table of Contents
loading

Related Manuals for Daikin FTXS09HVJU

Summary of Contents for Daikin FTXS09HVJU

  • Page 1: Operation Manual

    DAIKIN ROOM AIR CONDITIONER OPERATION MANUAL MODELS FTXS09HVJU FTXS12HVJU...

  • Page 2: Table Of Contents

    CONTENTS READ BEFORE OPERATION Safety Precautions ..............2 Name of Parts ................4 Preparation before Operation ...........8 OPERATION AUTO · DRY · COOL · HEAT · FAN Operation .......10 Adjusting the Airfl ow Direction ..........12 INTELLIGENT EYE Operation ..........13 POWERFUL Operation ............15 OUTDOOR UNIT QUIET Operation ........16 HOME LEAVE Operation ............17 TIMER Operation ..............19...

  • Page 3: Safety Precautions

    Do not attempt to repair, relocate, modify or reinstall the air conditioner by yourself. Incorrect work or modifi cations could cause electric shocks, fi re or other damage. For repairs and reinstallation, consult your Daikin dealer for advice and information. •...
  • Page 4 Arrange the drain hose to ensure smooth drainage. Improper drainage may cause water damage to the building, or it’s furnishing. • Depending on the usage environment, water may leak from the air conditioner. If this happens, contact your Daikin Dealer. •...

  • Page 5: Name Of Parts

    Name of Parts Indoor Unit Air-purifying fi lter with photocatalytic deodorizing function Air inlet Front panel Air fi lter Panel tab Room temperature Air outlet sensor • It senses the air temperature around the unit. Louvers (vertical blades) Page 12 INTELLIGENT EYE •...
  • Page 6 Open the front panel Air fi lter Air-purifying fi lter with photocatalytic deodorizing function Outdoor Unit • Appearance of the outdoor unit may differ from some models. Air inlet: (Back and side) Refrigerant piping and inter-unit cable Air outlet Drain hose Earth terminal •...

  • Page 7: Front Cover

    Name of Parts Remote Controller: ARC452A7 Signal transmitter Receiver Display (LCD) • It displays the current settings. (In this illustration, each section is shown with its displays ON for the purpose of explanation.) • To use the remote controller, aim the transmitter at the indoor unit.

  • Page 8: Quiet Button

    Open the front cover MODE selector button HOME LEAVE button • It selects the operation mode. • HOME LEAVE operation (AUTO/DRY/COOL/HEAT/ Page 17 FAN) Page 10 SWING button • Adjusting the Airfl ow Direction Page 12 SENSOR button QUIET button •...

  • Page 9: Preparation Before Operation

    Preparation before Operation To set the batteries Slide the front cover to take it off. Position – correctly! Set 2 dry batteries AAA.LR03 (alkaline). Set the front cover as before. To fi x the remote controller holder on the wall Choose a place from where the signals reach Set.
  • Page 10 Turn the breaker ON • Turning ON the breaker closes the fl ap. (This is a normal procedure.) To set the clock Press “ ” is displayed. “ ” and “ ” blinks. Press to set the current day of the week. Press “...

  • Page 11: Auto · Dry · Cool · Heat · Fan Operation

    AUTO · DRY · COOL · HEAT · FAN Operation The air conditioner operates with the operation mode of your choice. From the next time on, the air conditioner will operate with the same operation mode. To start operation Press and select a operation mode.
  • Page 12 To change the airfl ow rate setting Press DRY mode AUTO or COOL or HEAT or FAN mode Five levels of airfl ow rate setting from The airfl ow rate setting is not variable. “ ” to “ ” plus “ ”...

  • Page 13: Adjusting The Airfl Ow Direction

    Adjusting the Airfl ow Direction You can adjust the airfl ow direction to increase your comfort. Adjusting the upper and lower airfl ow direction To adjust the fl aps (horizontal blades) Press “ • ” is displayed on the LCD and the fl aps will begin to swing. When the fl...

  • Page 14: Intelligent Eye Operation

    INTELLIGENT EYE Operation “INTELLIGENT EYE” is the infrared sensor which detects the human movement. To start INTELLIGENT EYE operation Press “ • ” displayed on the LCD. To cancel the INTELLIGENT EYE operation Press again. “ • ” disappears from the LCD. [EX.] When somebody in the room •...
  • Page 15 INTELLIGENT EYE Operation To adjust the angle of the INTELLIGENT EYE sensor • You can adjust the angle of the INTELLIGENT EYE sensor to increase the detection area. (Adjustable angle: 15° to right and left of centre) INTELLIGENT EYE 15° 15°...

  • Page 16: Powerful Operation

    POWERFUL Operation POWERFUL operation quickly maximizes the cooling (heating) effect in any operation mode. You can get the maximum capacity. To start POWERFUL operation Press during operation. • POWERFUL operation ends in 20 minutes. Then the system automatically operates again with the previous settings which were used before POWERFUL operation.

  • Page 17: Outdoor Unit Quiet Operation

    OUTDOOR UNIT QUIET Operation OUTDOOR UNIT QUIET operation lowers the noise level of the outdoor unit by changing the frequency and fan speed on the outdoor unit. This function is convenient during night. To start OUTDOOR UNIT QUIET operation Press “...

  • Page 18: Home Leave Operation

    HOME LEAVE Operation HOME LEAVE operation is a function which allows you to record your preferred temperature and airfl ow rate settings. To start HOME LEAVE operation Press “ • ” is displayed on the LCD. • The HOME LEAVE lamp lights up. Control panel To cancel HOME LEAVE operation Press...

  • Page 19: Use As Energy-Saving Mode

    What’s the HOME LEAVE operation? Is there a set temperature and airfl ow rate which is most comfortable, a set temperature and airfl ow rate which you use the most? HOME LEAVE operation is a function that allows you to record your favorite set temperature and airfl ow rate. You can start your favorite operation mode simply by pressing the HOME LEAVE button on the remote controller.

  • Page 20: Timer Operation

    TIMER Operation Timer functions are useful for automatically switching the air conditioner on or off at night or in the morning. You can also use OFF TIMER and ON TIMER in combination. To use OFF TIMER operation • Check that the clock is correct. If not, set the clock to the present time.
  • Page 21 TIMER Operation To use ON TIMER operation • Check that the clock is correct. If not, set the clock to the present time. Page 9 Press “ ” is displayed. “ ” blinks. Press until the time setting reaches the point you like.

  • Page 22: Care And Cleaning

    Care and Cleaning CAUTION Before cleaning, be sure to stop the operation and turn the breaker OFF. Units Indoor unit, Outdoor unit and Remote controller Wipe them with dry soft cloth. Front panel Open the front panel. • Hold the panel by the tabs on the two sides and lift it unitl it stops with a click.
  • Page 23 Care and Cleaning Filters Open the front panel. Page 21 Pull out the air fi lters. • Push a little upwards the tab at the center of each air fi lter, then pull it down. Take off the Air-purifying fi lter with photocatalytic deodorizing Air-purifying filter with photocatalytic...
  • Page 24 Air Filter Wash the air fi lters with water or clean them with vacuum cleaner. • If the dust does not come off easily, wash them with neutral detergent thinned with lukewarm water, then dry them up in the shade. •...
  • Page 25 Care and Cleaning NOTE • Operation with dirty fi lters: cannot deodorize the air. cannot clean the air. results in poor HEAT or COOL. may cause odour. • To order Air-purifying fi lter with photocatalytic deodorizing function contact to the service shop there you bought the air conditioner. •...

  • Page 26: Trouble Shooting

    Trouble Shooting These cases are not troubles. The following cases are not air conditioner troubles but have some reasons. You may just continue using it. Case Explanation Operation does not start soon. • • When ON/OFF button was pressed soon after This is to protect the air conditioner.
  • Page 27 Trouble Shooting Check again. Please check again before calling a repair person. Case Check • Hasn’t a breaker turned OFF or a fuse blown? • The air conditioner does not operate. Isn’t it a power failure? (OPERATION lamp is off.) •...

  • Page 28: Call The Service Shop Immediately

    Call the service shop immediately. WARNING When an abnormality (such as a burning smell) occurs, stop operation and turn the breaker OFF. Continued operation in an abnormal condition may result in troubles, electric shocks or fi re. Consult the service shop where you bought the air conditioner. Do not attempt to repair or modify the air conditioner by yourself.
  • Page 29 Fault diagnosis. FAULT DIAGNOSIS BY REMOTE CONTROLLER In the ARC452A series, the temperature display sections on the main unit indicate corresponding codes. When the TIMER CANCEL button is held down for 5 seconds, a “ ” indication fl ashes on the temperature display section. TIMER CANCEL button It cancels the timer setting.
  • Page 30 Two-dimensional bar code is a code for manufacturing. 3P232717-1C M08B052A (0901) HT...
