B. Factory default values

Key-in keypad time: 10 seconds.
Door release time: 1 second
Programming time: 2 minutes
5-digit Pin code and master code: 12345

C. Audible signals

1 short beep
1 long beep
2 short beeps
4 short beeps

D. Visual signals

LED colour
Flashing orange
Orange
Green
Red

E. Consumption

In stand-by: 4 mA In use: 15 mA max

II. PROGRAMMING

A. Time outputs

Enter the master code twice (for the first use the master code default value is 12345). The orange LED
lights and two beeps sound to confirm entry into programming mode.
Press 0 then enter the 'key in' time in seconds: 10 for 10 seconds up to 99 for 99 seconds. The LED lights
off during 1 second and a beep will sound to confirm that the time has been accepted.
Press 1, then enter the door release time in seconds: 01 for 1 second up to 99 for 99 seconds. Enter 00 for
a latched output. The LED lights off for 1 second and a beep will sound to confirm that the time has been
accepted.
Press # to exit from programming mode. 2 beeps confirm that unit is back to reading mode.
4 beeps indicate a data computing error.

B. Code length

Enter the master code twice (for the first use the master code default value is 12345). The orange LED and
two beeps sound to confirm entry in the programming mode.
Press 2 to program the code length then enter 3, 4, 5, 6, 7 or 8 The LED lights off for 1 second and a beep
sound to confirm that the new code length has been accepted.
IMPORTANT: When the code length has been modified, the Master code should be reprogrammed, in
the new code format, also while in programming.
2
Press a digit keypad
Data validated in programming or access granted
Entry or exit from programming
Data computing error
Normal operating
Stand-by
Access granted
programming
Data computing error
Programming menu
User number empty
User number busy
