Festo CPX-FVDA-P2 Manual
Festo CPX-FVDA-P2 Manual

Festo CPX-FVDA-P2 Manual

Output module
Hide thumbs Also See for CPX-FVDA-P2:

Advertisement

Quick Links

CPX-FVDA-P2
Output module
Brief description
8076421
2018­10b
[8076423]
Translation of the original instructions
PI PROFIBUS PROFINET
®
, PROFIsafe
trademark owners in certain countries.
1
Safety instructions
Installation and commissioning must be carried out only by properly qualified per­
sonnel in accordance with these operating instructions.
WARNING!
Non­observance of safety regulations can result in death, serious injuries or major
material damage.
The safety instructions must be observed.
NOTICE!
Electronics modules include electrostatically sensitive devices.
Incorrect handling can cause damage to the electronics modules.
Observe the handling specifications for electrostatically sensitive devices.
Discharge static electricity from your body before assembling or disas­
sembling modules to protect the modules.
NOTICE!
To ensure compliance with the intended use:
Each output channel that is in use must be switched at least once a week.
If test pulses are switched off:
Each output that is in use must be switched at least once a day.
NOTICE!
To ensure compliance with the safety level:
Each output channel that is in use must be switched on for more than
1 minute at least once every 8 operating hours.
The operating time begins when the output module is first switched on.
NOTICE!
Use a maximum of 2 output channels in a common safety pilot circuit.
Observe the regulations for providing voltage (protective extra­low voltage, PELV)
to CPX terminals in the system description CPX­SYS­... è www.festo.com/sp
1.1
Symbols
Identification of dangers and notes on how to avoid them:
WARNING!
Dangers which can lead to death or serious injuries.
CAUTION!
Dangers which can lead to slight injuries or to serious material damage.
Other symbols:
NOTICE!
Material damage or loss of function
Recommendation or tip
ENVIRONMENT!
Information on environmentally friendly use
Festo AG & Co. KG
Ruiter Straße 82
73734 Esslingen
Germany
+49 711 347­0
www.festo.com
8076421
®
are registered trademarks of the respective
Link to accessories è www.festo.com/catalogue
1.2
Intended use
The output module CPX­FVDA­P2 is used correctly as a shut­off module for the
safe shutdown of connected consumers (safety function) if the following condition
is met:
The connected consumers go into a safe state when the safety shutdown
takes place.
Product versions
The output module CPX­FVDA­P2 is available in three versions
è Tab. 4 Permissible components:
Version 1
in combination with certain manifold and interlinking blocks of the CPX ter­
minal
Version 2
as part of the pneumatic interface VABA­S6­1­X...­F1­CB of the valve terminal
VTSA­F­CB
Version 3
as part of the pneumatic interface VABA­S6­1­X...­F2­CB of the valve terminal
VTSA­F­CB
Safety function
The safety function is achieved through dual­channel, P­ and M­side disconnec­
tion of the load voltage supply for U
Version 1
Disconnection of the load voltage supply for U
minal: output channel CH0 of the module.
Output channel CH0 is used to supply valve terminal pneumatic modules
in the CPX terminal fitted on the right­hand side.
Disconnection of the two outputs provided through the connection tech­
nology of the module: output channel CH1 and CH2 of the module, also
supplied via the load voltage supply for U
In addition, the unswitched load voltage supply U
through the connection technology of the module as operating voltage for the
external components (24 V DC auxiliary supply).
Version 2
Disconnection of the three internal safe voltage zones: CH0, CH1, CH2.
Version 3
Disconnection of the two internal safe voltage zones: CH0, CH1.
Disconnection of the safe output provided through the connection tech­
nology of the pneumatic interface: CH2.
The voltage zones can be disconnected independently of each other in an
electrically safe manner.
The output channels of the output module CPX­FVDA­P2 each form a safety circuit
with their connected consumers.
Information about the power supply for the CPX terminal è System description
CPX­SYS­...
Range of application
The output module CPX­FVDA­P2 is a product with safety­relevant functions and is
intended for installation in machines or automation systems and for use as fol­
lows:
In excellent technical condition
In its original condition, without unauthorised modifications
Only in the configurations named in the description CPX­FVDA­P2­...
Within the limits of the product defined by the technical data
è 7 Technical data
In an industrial environment
NOTICE!
Note that the safety limits of the output module are also its physical limits.
1.3
Rules for product configuration
Operation of the output module CPX­FVDA­P2 is permissible only in CPX ter­
minals from Festo of the variant CPX­M­... or in pneumatic interfaces for the
valve terminal VTSA­F­CB­...
Comply with all technical operating limits è 7 Technical data. Otherwise,
malfunctions can occur.
Operation of the CPX­FVDA­P2 is permissible only in combination with the fol­
lowing PROFIsafe­compatible CPX bus nodes è Bus node rating plate:
Bus node
From revision
CPX­FB13
1)
30
CPX­FB33
2)
21
2)
CPX­M­FB34
21
2)
CPX­M­FB35
21
1) è Description CPX­FB13...
2) è Description CPX­PNIO...
Tab. 1 Permissible PROFIsafe­compatible CPX bus nodes
valves:
VAL
valves of the CPX ter­
VAL
valves.
VAL
is made available
VAL
Network protocol
PROFIBUS
PROFINET IO
PROFINET IO
PROFINET IO
