Table 3. Suggested Total Input Capacitance for Different Input Voltage Ranges.
The capacitance is used to calculate the minimum and maximum DC
voltage across the bulk capacitor and should be selected to keep the
minimum DC input voltage, VMIN > 70 V.
Nominal Output Voltage, VOUT (V)
Enter the nominal output voltage of the main output at full load.
Usually the main output is the output from which feedback is derived.
Cable Compensation, PERCENT_CDC (%)
Select the appropriate cable compensation depending on the choice
of cable for the design. If this power supply is not supplied with a
cable, use the default 0%. (For InnoSwitch3-EP, this feature is not
available)
Power Supply Output Current, IOUT (A)
This is the maximum continuous load current of the power supply.
Output Power, POUT (W)
This is a calculated value and will be automatically adjusted based on
cable compensation selected.
Power Supply Efficiency, EFFICIENCY (η)
Enter the estimated efficiency of the complete power supply
measured from the input and output terminals under peak load
conditions and worst-case line (generally lowest input voltage). The
table below can be used as a reference. Once a prototype has been
constructed then the measured efficiency should be entered and
further transformer iteration(s) can be performed if required.
Nominal Output
Voltage (VOUT)
5
12
Table 4. Efficiency Estimate Without Output Cable .
www.power.com
Total Input Capacitance per Watt of
Output Power (µF/W)
Adapter with hold-up time requirement
Typical Low-Line Range
85 VAC - 132 VAC
Schottky Diode Synchronous
Rectifier Rectifier
0.84 0.87
0.86 0.90
Full Wave Rectification
Open Frame or Charger/Adapter without
3
1
3
Power Supply Loss Allocation Factor, FACTOR_ Z
This factor describes the apportioning of losses between the primary
and the secondary of the power supply. Z factor is used together
with the efficiency to determine the actual power that must be
delivered by the power stage. For example losses in the input stage
(EMI filter, rectification etc) are not processed by the power stage
(transferred through the transformer) and therefore although they
reduce efficiency the transformer design is not effected.
For designs that do not have a peak power requirement, a value of
0.5 is recommended. For designs with a peak power requirement
enter 0.65. The higher number indicates larger secondary side
losses.
Enclosure
Power device selection will also be dependent on the application
environment. For an open frame application where the operating
ambient temperature is lower than in an enclosed adapter, the PIXls
will suggest a smaller device for the same output power.
Efficiency is also a function of output power, low power designs are
most likely around 84% to 85% efficient, whereas with a synchronous
rectifier (SR) the efficiency would reach 90% typically.
Typical Universal Range
85 VAC - 265 VAC
Schottky Diode Synchronous
Rectifier Rectifier
0.84 0.88
0.86 0.90
Application Note
Total Input Capacitance per Watt of
Output Power (µF/W)
hold-up time requirement
2
1
2
Secondary Losses
Z =
Total Losses
Typical High-Line Range
185 VAC - 265 VAC
Schottky Diode
Rectifier
0.87
0.88
Synchronous
Rectifier
0.89
0.90
5
