• Enter AC input voltage range and line frequency, VAC_MIN [B3],
VAC_MAX [B4], LINEFREQ [B6]
• Enter input capacitance, CAP_INPUT [B7]
• 3 µF / W for universal (85-265 VAC) or single (100/115 VAC) line.
A more aggressive value of 2 µF / W can be used for many
charger designs that do not need to meet hold up time require-
ment
• Use 1 µF/W for 230 VAC or for single (185-265 VAC) line. If this
cell is left blank then the capacitance value for a VMIN of 70 V
(universal input) or 150 V (single 230 VAC) is calculated. Often
this will lead to an optimal input filter capacitance value
• Enter nominal output voltage, VOUT [B8]
• Enter desired cable drop compensation, PERCENT_CDC [B9]
• "0%" for no cable compensation
• "1% - 6%" for featured H-code trim
• Enter continuous output current, IOUT [B10]
• Enter efficiency estimate, EFFICIENCY [B12]
• 0.83 for universal input voltage (85-265 VAC) or single 100/115
VAC (85-132 VAC) and 0.85 for a single 230 VAC (185-265 VAC)
design. Adjust the number accordingly after measuring the
efficiency of the first prototype-board at max load and VACMIN
• Select power supply enclosure, ENCLOSURE [B14]
• Select current limit mode, ILIMIT_MODE [B19]
• Two current limit configurations are available, STANDARD or
INCREASED

Output Power Table

230 VAC ± 15%
Product
3
Adapter
INN3162C 10 W
INN3163C
12 W
INN3164C
20 W
INN3165C
25 W
INN3166C 35 W
INN3167C 45 W
INN3168C 55 W
Notes:
1. Minimum continuous power in a typical non-ventilated enclosed typical size
adapter measured at 40 °C ambient. Max output power is dependent on the
design. With condition that package temperature must be < 125 °C.
2. Minimum peak power capability.
3. Package: InSOP-24D.
Table 1. Output Power Tables of InnoSwitch3-CE and EP.
www.power.com
85-265 VAC
Open Open
Adapter
1 1
Frame Frame
2
12 W 10 W 10 W
15 W 12 W 12 W
25 W 15 W 20 W
30 W 22 W 25 W
40 W 27 W 36 W
50 W 40 W 45 W
65 W 50 W 55 W
• Select InnoSwitch3 from drop-down list or enter directly [B20]
• Select the device from Table 1 according to output power, input
voltage and application
• InnoSwitch3-CE for CV/CC flyback application
• InnoSwitch3-EP for CV/CC flyback application with 725 V
MOSFET
• Enter desired maximum switching frequency at full load, FSWITCH-
ING_MAX [B34]
• Enter desired reflected output voltage, VOR [B35]
• Enter core type (if desired), CORE [B63] from drop down menu
• Suggested core size will be selected automatically if none is
entered [B63]
• For custom core, enter CORE CODE [B64], and core parameters
from [B65] to [B72]
• Enter secondary number of turns [B88]
If any warnings are generated, make changes to the design by
following instructions in spreadsheet column D.
• Build transformer as suggested in "Transformer Construction" tab
• Select key components
• Build prototype and iterate design as necessary, entering measured
values into spreadsheet where estimates were used (e.g. efficiency,
V ). Note that the initial efficiency estimate is very conservative.
MIN
Output Power Table
230 VAC ± 15%
Product
3
Open Frame
2
INN3672C
INN3673C
INN3674C
INN3675C
INN3676C
INN3677C
Notes:
1. Minimum continuous power in a typical non-ventilated enclosed typical size
adapter measured at 40 °C ambient. Max output power is dependent on the
design. With condition that package temperature must be < 125 °C.
2. Minimum peak power capability.
3. Package: InSOP-24D.
Application Note
85-265 VAC
Peak or Peak or
Open Frame
1,2
12 W 10 W
15 W 12 W
25 W 20 W
30 W 25 W
40 W 36 W
45 W 40 W
1,2
3
