Power integrations InnoSwitch3 Application Note page 26

Application Note
AC Input
Fuse
Thermistor
AC Input
Figure 22. TOP Side – Layout Example Showing Through-Hole Components.
26
Rev. A 10/18
Input Filter
Capacitors
EMI Filter
Inductor
Safety
Y Capacitor
Output
Capacitor
Transformer
AN-72
Output
Terminals
PI-8521-103117
