Binks SG-2 Plus Manual

INTRODUCTION
Binks SG-2 Plus Rotary 2 Qt. Pressure Cup is ideal for compo-
TM
nent spraying and industrial applications where small batch pro-
duction spraying is required. The 2 qt. capacity is sufficient to
complete large spray jobs without refilling the cup. Its lightweight
and rugged construction is excellent for portability, allowing the
operator to make fluid and air control adjustments quickly and
efficiently at the spray station.
The internal construction is designed for waterborne and
solvent base materials.
Other features include:
• Stainless steel pick-up tube, fluid fittings and
removable plastic liner makes it corrosion resistant.
• "Wide-mouth" opening allows easy cleaning, plastic liner
removal and quick color change.
• Positive grip carrying handle for operator comfort.
• Wide stainless steel base for stability and corrosion
resistance.
• 0-50 psig fluid pressure range.
• Optional 0-10 psi pressure kit.
• Silverstone coated on interior and exterior of lid.
®
• Rotary agitator for metallics and paints requiring
continuous agitation.
• Mixed flow impeller for superior agitation with
minimal vortex.
SPeCIfICaTIONS
max. WORKING pRessuRe ....................... 50 psig
OVeRaLL HeIGHT ....................................... 15 11/16 in.
Base DIameTeR ......................................... 6 in.
DIa. aCROss CLOseD CLamps ................... 8 1/16 in.
DIa. aCROss OpeN CLamps ...................... 8 1/16 in.
aIR INLeT & OuTLeT CONNeCTION sIZe ... 1/4 Nps (m)
FLuID OuTLeT CONNeCTION sIZe .............. 3/8 Nps (m)
FLuID CapaCITY .......................................... 2 Qts. (u.s.)
WeIGHT ....................................................... 7lb.5oz.
aGITaTOR aIR CONsumpTION .................. 2.5 cfm @
WaRNING
!
all air and fluid pressure in the system must be relieved
before servicing the cup and before cup is filled or cleaned.
Attempting to service the cup while pressurized could
result in damage to components or personal injury.
Binks
RoTaRy 2 QT. PRESSURE CUP
Model No. 80-651—Rotary agitator
3.5 kg/cm
2
39.88 cm
15.24 cm
20.47 cm
20.47 cm
--
--
1.9 Liters
3.3 kg.
7.5 cfm @
40 psi 100 psi
SG-2 Plus
®
Replaces
part sheet
77-2842R-1
TM
Part
Sheet
77-2842R-2
