  • Page 1 ES 030-10...

  • Page 2: Safety Instructions

    Elektronika shall not be liable for user’s failure to comply with these requirements. Installation Category The Delta Elektronika power supplies have been evaluated to installation category II (Over voltage category II). Grounding of Mains Input This product is a safety Class 1 instrument. To minimize shock hazard, the instrument chassis must be connected to the AC Power Supply mains through a three or four conductor power cable for resp.

  • Page 3: Input Ratings

    Parts Substitutions & Modifications Parts sub sti tu tions and mod i fi ca tions are al lowed by au tho rized Delta Elektronika ser vice per son nel only. For re pairs or mod i fi ca tions the unit must be re turned to a Delta Elektronika ser vice facility.

  • Page 4: Environmental Conditions

    ES030-10 DELTA ELEKTRONIKA BV Environmental Conditions The Delta Elektronika power supplies safety approval applies to the following operating conditions: Indoor use : -20 to 50 °C Ambient temperature : 95%, non condensing, up to 40 °C Maximum relative humidity : 75%, non condensing, up to 50 °C...
  • Page 5 ES030-10 DELTA ELEKTRONIKA BV Cir cuit de scrip tion Sim pli fied func tional di a gram The in put volt age is rec ti fied by a bridge rec ti fier. A boost-type con verter con verts this volt age to about 370 V.
  • Page 6 The mon i tor out puts of volt age and cur rent are 0-5 V and pro por tional to the out put volt age and cur rent. The pro gram ming con nec tor is a 15 pole D-con nec tor which is pin com pat i ble with other Delta Elektronika power sup plies and with the ex ter nal IEEE488 in ter face.
  • Page 7 Ethernet / IEEE488 / RS232 pro gram ming The Delta Elektronika PSC-ETH and PSC-232 con trol lers can be built in side the power sup ply. The 15 pole D-con nec tor on the power sup ply is pin com pat i ble with the ex ter nal IEEE488 in ter face (PSC-488 module).
  • Page 8 DELTA ELEKTRONIKA BV ES030-10 Set ting up Mas ter / Slave op er a tion: • Connect the out put ter mi nals and test the sys tem in nor mal par al lel or se ries op er a tion. En sure that all (out put) power con nec tions are re li able.
  • Page 9 ES030-10 DELTA ELEKTRONIKA BV In su la tion For safety the in su la tion of the seperating com po nents (trans form ers) be tween in put and out put is tested at 3750 Vrms dur ing 1 min ute. This is tested be fore as sem bly.
  • Page 10 P.O. Box 27 Tel. +31 111 413656 DELTA ELEKTRONIKA B.V. 4300 AA Zierikzee Fax. +31 111 416919 The Netherlands www.deltapowersupplies.com EC Dec la ra tion of Con for mity Delta Elektronika P.O. BOX 27 4300 AA Zierikzee The Neth er lands...
