Silicon Laboratories Si47 Series Programming Manual page 181

Response
Bit D7
CTS
STATUS
0
RESP1
RESP2
RESP3
RESP Bit Name
1 7:0 Reserved
2 7:0 PROPV
3 7:0 PROPV
Command 0x14. GET _ INT _ STATUS
Updates bits 6:0 of the status byte. This command should be called after any command that sets the STCINT,
RSQINT, SAMEINT (Si4707 only), or ASQINT bits. When polling this command should be periodically called to
monitor the status byte, and when using interrupts, this command should be called after the interrupt is set to
updated the status byte. The CTS bit (and optional interrupt) is set when it is safe to send the next command. This
command may only be sent when in powerup mode.
Available in: All
Command arguments: None
Response bytes: One
Command
Bit D7
0
CMD
Response
Bit D7
CTS
STATUS
D6 D5
ERR X
0 0
Always returns 0.
[7:0]
Property Value High Byte.
H
This byte in combination with PROPV
property value.
[7:0]
Property Value High Byte.
L
This byte in combination with PROPV
property value.
D6 D5
0 0
D6 D5
ERR X
Rev. 0.8
D4 D3 D2
X RSQINT SAMEINT
0 0
PROPV [7:0]
H
PROPV [7:0]
L
Function
will represent the requested
L
will represent the requested
H
D4 D3
1 0
D4 D3 D2
X RSQINT SAMEINT
AN332
D1 D0
ASQINT STCINT
0 0 0
D2 D1 D0
1 0 0
D1 D0
ASQINT STCINT
181
