Table 5. FM Transmitter Property Summary (Continued)
Prop
0x2C01 TX_RDS_PI
0x2C02 TX_RDS_PS_MIX
0x2C03 TX_RDS_PS_MISC
0x2C04 TX_RDS_PS_REPEAT_COUNT
0x2C05 TX_RDS_PS_MESSAGE_COUNT
0x2C06 TX_RDS_PS_AF
0x2C07 TX_RDS_FIFO_SIZE
Notes:
1. Digital Audio Input feature (property DIGITAL_INPUT_FORMAT and DIGITAL_INPUT_SAMPLE_RATE) is supported
in FMTX component 2.0 or later.
2. RDS feature (command TX_RDS_BUFF, TX_RDS_PS and RDS properties 0x2103, 0x2C00 through 2C07) is
supported in FMTX component 2.0 or later.
3. Limiter feature (LIMITEN bit in TX_ACOMP_ENABLE and property TX_LIMITER_RELEASE_TIME) is supported in
FMTX component 2.0 or later.
10
Name
2
Sets transmit RDS program identifier. 0x40A7
Configures mix of RDS PS Group
2
with RDS Group Buffer.
Miscellaneous bits to transmit along
2
with RDS_PS Groups.
Number of times to repeat transmis-
2
sion of a PS message before trans-
mitting the next PS message.
2
Number of PS messages in use.
RDS Program Service Alternate Fre-
quency. This provides the ability to
inform the receiver of a single alter-
2
nate frequency using AF Method A
coding and is transmitted along with
the RDS_PS Groups.
Number of blocks reserved for the
FIFO. Note that the value written
2
must be one larger than the desired
FIFO size.
Description
Rev. 0.8
Available In
Default
Si4711/13/21
0x0003 Si4711/13/21
0x1008 Si4711/13/21
0x0003 Si4711/13/21
0x0001 Si4711/13/21
0xE0E0 Si4711/13/21
0x0000 Si4711/13/21
