Property 0x5202. WB_RSQ_SNR_LO_THRESHOLD
Sets low threshold which will trigger the RSQ interrupt if the Audio SNR is below this threshold. The CTS bit (and
optional interrupt) is set when it is safe to send the next command. This property may only be set or read when in
powerup mode. The default is 0dB.
Available in: All
Default: 0x0000
Units: dB
Step: 1
Range: 0-127
Bit D15 D14 D13
Name
Bit Name
15:0 SNRL
Property 0x5203. WB_RSQ_RSSI_HI_THRESHOLD
Sets high threshold which will trigger the RSQ interrupt if the RSSI is above this threshold. The CTS bit (and
optional interrupt) is set when it is safe to send the next command. This property may only be set or read when in
powerup mode. The default is 127dB.
Available in: All
Default: 0x007F
Units: dBµV
Step: 1
Range: 0-127
Bit D15 D14 D13
Name
Bit Name
15:0 RSSIH
D12 D11 D10
WB RSQ Audio SNR Low Threshold.
Threshold which will trigger the RSQ interrupt if the Audio SNR is below this threshold.
Specified in units of dB in 1 dB steps (0...127). Default is 0dB.
D12 D11 D10
WB RSQ RSSI High Threshold.
Threshold which will trigger the RSQ interrupt if the RSSI is above this threshold.
Specified in units of dB in 1 dB steps (0...127). Default is 127dB.
D9 D8 D7 D6 D5
SNRL[15:0]
Function
D9 D8 D7 D6 D5
RSSIH[15:0]
Function
Rev. 0.8
AN332
D4 D3 D2 D1 D0
D4 D3 D2 D1 D0
