Dalsa Falcon2 Series User Manual page 118

Full Name
set output line source
Mnemonic
sos
Argument(s)
line
source
GenICam
LineSelector
outputLineSource
Release
6
Notes
Defines the internal signal to output on the specified general purpose output line.
Full Name
set output pulse delay
Mnemonic
soy
Argument(s)
line
delay
GenICam
LineSelector
outputLinePulseDelay
Release
6
Notes
The amount of time(in milliseconds) to delay the output pulse, after detecting a signal.
Full Name
set pixel output format
Mnemonic
spf
Argument(s)
bitsPerPixel
GenICam
PixelFormat
Release
6
Notes
Sets the pixel size of the camera output
118 •
L3: general purpose output 1
L4: general purpose output 2
0:Start Internal ExSync
1:Start Exposure
2:End Exposure
3:Strt Readout
4:End Readout
5:End Internal EXSYNC
6:Start Line Active
7:GP Input 1
8:GP Input 2
9:CC1
10:CC2
11:CC3
12:CC4
13:End Line Active
30:Software Controlled
31:Off
L3: general purpose output 1
L4: general purpose output 2
1~8388608 [µs]
8
10 (only available when using 8 camera link taps)
Appendix E: Three Letter Commands
