Introduction BOA Vision System Overview BOA is a fully integrated vision system in a compact “smart” camera format that has been specifically designed for industrial use. Packaged complete with application software embedded, BOA provides an easy-to-deploy automated inspection system for the factory floor. -
Page 7: Components
BOA Vision System Components BOA vision systems are shipped with the components listed below. Take a few moments to verify that everything has arrived in good condition. If your product has been visibly damaged during shipment or is missing parts, please contact your Teledyne DALSA representative immediately. -
Page 8: Installation
Installation Connecting the BOA Vision System This section details how to connect the BOA vision system with its associated components and factory environment. Camera Connectors and Indicators Designator Definitions 10/100 BaseT Ethernet connection. Provides the primary interface for configuring the camera, developing the application and monitoring results. -
Page 9: Cable Pinouts
Cable Pinouts The BOA vision system is compatible with M12 factory cordsets as show below: LAN Connector Pinout and Cordset Name RJ45 Pin PWR * GND * TXD- RXD+ TXD+ RXD- A-CAB-BVS-E8S-X I/O-PWR Connector Pinout and Cordset Name Color TRIG... -
Page 10: Cable Configurations
Cable Configurations The BOA vision system offers flexible cabling options to suit a number of application configurations: For single cable applications, the Ethernet cable can be used to supply power (referred to as “Passive Power over Ethernet”) and communications between the camera and the control environment. -
Page 11: Ethernet Only Setup
Connect camera PWR and GND to the breakout screw terminals labeled “PWR” Connect the Lamp via corset A-BVS-L5S-X between the camera (M12-5 and the lamp) Setup Computer, PLC or Factory A-BVS-PL-100 Network A-BVS-E8S-X Cat5 Cable BOA System A-BVS-L5S-X LED Lamp Version 06 teledynedalsa.com/ipd... -
Page 12: Ethernet And I/O Setup
8 female connector on the camera labeled “I/O PWR” Connect the open-ended wires of the IO-PWR cordset to their respective connections on the breakout module. Setup Computer, PLC A-BVS-PL-100 or Factory Network A-BVS-E8S-X A-BVS-IO8S-X Cat5 Cable BOA System LED Lamp A-BVS-L5S-X Version 06 teledynedalsa.com/ipd... -
Page 13: Getting Started
NOTE: A power cycle is required before the new address will take effect. If you incorrectly set, or forgot, the new address of your BOA, you can run the “iDiscover” utility. This program is installed automatically when you click on the “iNspect Express”... -
Page 14: Idiscover Utility
(“Start programs -> Run”), type “iDiscover” and click “OK” If the connecting PC has not previously been used to interface a BOA camera, you must first install the iNspect software emulator. Once installed, the program can be invoked from the iDiscover shortcut (“Start programs ->... -
Page 15: Boa Web Server
BOA Web Server The BOA web server is a portal through which the BOA system can be set up and configured for an application. The web server is accessed from a host PC using Microsoft Internet Explorer version 6 or higher as follows: Open Internet Explorer on the configured PC connected to the camera Enter the URL address of the camera: 192.168.0.100 and click “go”... -
Page 16: Firmware Updating
Firmware Upgrading BOA firmware may need to be updated occasionally to add new features or fix reported problems. To do this, click on the “Upgrade Device” hotlink to launch the upgrade control. -
Page 17: The Boa Emulator
Upgrade multiple cameras Note 1: When you access BOA through this interface, it is important that you maintain version compatibility between the camera and the emulator. Note 2: Some shortcuts and programs are only available with versions 1700 or above Version 06 teledynedalsa.com/ipd... -
Page 18: Specifications
Specifications General Specifications This following table lists the specifications of the BOA vision system: Specification Definition Memory Storage 256 MB Storage; 256MB Program Image Sensor 1/3 inch CCD; 7.4 μm pixel size Resolution 640x480 Type Mono or Color Progressive Scan... -
Page 19: Input Specifications
Input Specifications The BOA vision system provides two dedicated opto-isolated, polarity independent inputs. One of the inputs provides the acquisition Trigger function, while the other is general purpose. Specification Definition Voltage 12-30 V 0-3 V (12 V nominal threshold) Current 7.5 mA typ (24 V applied) -
Page 20: Output Specifications
Output Specifications The BOA vision system provides two dedicated opto-isolated, solid state relay outputs and a separate dedicated light strobe (pin 2 of lamp connector). Specification Definition Voltage (Vin) Load 24V maximum Current GPO[0:1] 100mA max (drives to OCMN when active) -
Page 21: Output Control
BOA will not generate a pass pulse even if the inspection passes. In this case, BOA will always generate a FAIL pulse if FAIL is selected on the second output. This would result in false rejects if the output is being used to control a directional device. -
Page 22: Panel Link Specification
The module also provides power over Ethernet for single cable applications. I/O connections to the BOA camera should be wired to the TOP connectors on the PL- 100 (J2 and J3) directly. NOTE: Avoid reversing PWR/GND on the I/O connector. Doing so may make the PoE feature unusable. -
Page 23: Panel Link Wiring
Panel Link Wiring Illustration Note: BOA side is a 1:1 connection using A-BVS-IO8 ICMN PL Ethernet ports not shown ICMN ERTH To BOA OUT0 OCMN OUT1 OUT1 PL-100 OCMN OUT0 IN0- TRG- TRG+ TRG- IN0+ IN0- To Control Panel OU0+... -
Page 24: Serial Port Connection
Party DSUB-9 Connector BOA LAMP M12-5 Connector Name Color Name RS232 RX White Blue RS232 TX Yellow Not required 1,4,6,7,8,9 Not required Note: It is important to establish a common ground between BOA and the connecting party device. Version 06 teledynedalsa.com/ipd... -
Page 25: Boa Mechanicals
BOA Mechanical Dimensions Front View Back View Note: All dimensions in mm Side View Bottom View Version 06 teledynedalsa.com/ipd... -
Page 26: Pl-100 Mechanicals
A-BVS-PL-100 Mechanical Dimensions Top View Note: All dimensions in mm Side View Version 06 teledynedalsa.com/ipd...
