TECHNICAL DATA
Rated input
Rated power
No-load speed
Wheel thickness
Wheel diameter
Arbour hole
Wheel type
Mitre capacity
Minimum workpiece dimensions
Weight according EPTA-Procedure 01/2003
Measured sound values determined according to EN 62841:
A-weighted sound pressure level
Uncertainty K
A-weighted sound power level
Uncertainty K
Wear ear protectors.
Maximum cutting capacity
0°
45°
REPLACEMENT PARTS
Cutting wheel
GENERAL POWER TOOL SAFETY WARNINGS
WARNING!
Read all safety warnings, instructions, illustrations and
specifications provided with this power tool. Failure to follow
all instructions listed below may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
WORK AREA SAFETY
Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
Do not operate power tools in explosive atmospheres, such as
in the presence of flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
20
METAL CUT OFF SAW
115 mm
115 mm
115 mm
100 mm
089210129800
120 x 115 mm
105 x 95 mm
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded)
power tools. Unmodified plugs and matching outlets will reduce risk
of electric shock.
Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased
risk of electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the
risk of electric shock.
When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use
a residual current device (RCD) protected supply. Use of an RCD
20
SMT355-1
230V - 240V ~ 50 Hz
2300 W
4280 min
3 mm
355 mm
25.4 mm
Type 41 reinforced abrasive wheel
Right 45˚ / Left 45˚
115 mm (L) x 3 mm (W) x 3 mm (H)
115 mm (L) x 3 mm (ø)
17 kg
91.5 dB (A)
3 dB (A)
104.5 dB (A)
3 dB (A)
130 mm
100 mm
-1
