1. Handle, insulated gripping surface
2. Trigger switch
3. Lower guard
4. Upper guard
5. Cutting wheel
6. Chip deflector
7. Cutting depth adjustment screw
8. Cutting depth lock nut
9. Work clamp
10. Work clamp lock lever
11. Work table
12. Work clamp adjustment crank
13. Rubber foot
14. Mitre guide lock lever
15. Mitre guide
16. Top handle
17. Spindle lock
18. Saw head lock chain
19. Wrench
20. Mounting hole
21. Carbon brush
22. Carbon brush cap
11
12
16
20
19
7
8
9
10
15
20
3
1
2
3
22
21
17
22
18
4
5
6
13
14
3
