Rear panel LED behavior
Table 2 describes the behaviour of the LEDs on the rear of the unit.
Table 2: Cisco TS 7010 rear panel LED behavior
LED
Ethernet Port Status:
FDX
100
1000
The front panel LCD will show the IP address assigned.
i
Admin Port Activity
Link Connectors
Color
Indicates
Green
The link has been established as a full-
duplex link
Green
The link is operating at 100Mbps. This
LED flashes to indicate activity
Green
The link is operating at 1000Mbps. This
LED flashes to indicate activity
Reserved for future expansion
Reserved for future expansion
LED behavior
