Rear panel LED behavior

Table 2 describes the behavior of the rear panel LEDs.
Table 2: MCU 5300 rear panel LED behavior
LED
Link
Net A
Net B
Color Indicates
Green Illuminated when the link between stacked
MCUs is active.
Green/ Left LED illuminated green when the
Orange interface has established a link. Right LED
illuminated orange when there is activity
on the interface.
Green/ Left LED illuminated green when the
Orange interface has established a link. Right LED
illuminated orange when there is activity
on the interface.
