QUICK REFERENCE GUIDE

1. Login and Logout

CAUTION
We recommend to use Internet Explorer 7 or latest version to access the ViewZ web management system.
Firefox will work with ViewZ web management system, but some function and layout might not work
perfectly.
Windows Edge and Chrome are currently not supported by ViewZ web management system.
Login
Step 1 Open Internet Explorer. Enter the IP address of the PVM IP camera (default value:
192.168.0.120) in the address box and then press Enter.
The login page is displayed, as shown in Figure 1-1.
Figure 1-1 Login Page
Step 2 Enter the user name, and password
Note
• The default user name is admin and the default password is admin. Change the password when you log in
to the system for the first time to ensure system security.
• You can change the system display language on the login page.
Step 3 Click Login. The main page will be displayed.
Logout
To log out of the system, click the icon
The login page is displayed after you log out of the system.
6
Factory Default IP address : 192.168.0.120
Factory Default Subnet Mask : 255.255.255.0
Factory Default Gateway : 192.168.0.1
Factory Default DNS 1 : 192.168.0.1
Factory Default DNS 2 : 192.168.0.2
Caution: IP address and gateway address should be set with the
same IP parameters. For example, if IP address is "A.B.C.0 ~
255", then gateway address should be set as "A.B.C.0~255"
(however, IP and gateway address cannot be the same.)
in the upper right corner of the main page.
