Introduction

This section covers the following:
•
•

About the ShareLink Pro 1000

The ShareLink Pro 1000 is a Wireless and Wired Collaboration Gateway that enables
anyone to present wireless or wired content from their computers, tablets, or smartphones
onto a display for easy collaboration.
It features streaming technology that supports simultaneous display of up to four content
sources, including an HDMI-connected device. The HDMI input supports wired connections
from any connected source in the room. To support a wide range of environments, the
ShareLink Pro 1000 has collaboration and moderator modes that facilitate both open and
restrictive environments.
The ShareLink Pro 1000 provides easy integration of AV and mobile devices into meeting,
huddle, collaboration, and presentation spaces.
Tablet
Figure 1.
About the ShareLink Pro 1000
Features
Extron
HDMI Show Me Cables
Wireless Access Point
Ethernet
Smartphone
Laptop
TCP/IP
Network
ShareLink Pro 1000 Application Diagram
INPUT OUTPUT CONTACT / TALLY OUTPUT
POWER
12V
AUDIO
1.7A MAX 1 2 3 4
L R
HDMI HDMI C T C T C T C T G +V
Extron
ShareLink Pro 1000
Wireless and Wired
Collaboration Gateway
ShareLink Pro 1000 • Introduction
Display
MODEL 80
FLAT PANEL
HDMI/CEC
COM LAN
RS-232 RESET
Tx Rx G
A/PoE B
Ethernet Ethernet
1
