INFORMATION: If the machine is left damp
for longer periods stains will appear. These
stains are harmless but the original surface
will lose its lustre. Vegetables and fruit contain
acids. Depending on which products are
processed this will have an effect on the metal
after varying periods of time. It is therefore
important to clean the machine immediately
after processing salty and acidic products.
TROUBLE SHOOTING
To eliminate the risk of damage to the motor,
the RG-200 is fitted with thermal motor
protection that automatically switches off the
machine if the temperature of the motor should
become too high. The thermal motor protection
has automatic reset, which means that the
machine can be started again when the motor
has cooled down, which usually takes between
10 and 30 minutes.
FAULT: The machine cannot be started,
or stops while it is running and cannot be
restarted.
REMEDY: Check that the plug is securely
fitted into the power supply socket. Check
that the feed cylinder is locked in the correct
position. Move down the pusher plate into
the feed cylinder. Check that the fuses in the
fuse box for the premises have not blown and
that they have the correct rating. Wait for a
few minutes and try to restart the machine. If
the machine still fails to run, call in a qualified
service mechanic.
FAULT: Low capacity or poor cutting results.
REMEDY: Make sure that you are using the
correct cutting tool or combination of cutting
tools. Fit the decoring device. Check that the
knives and grater/shredder plates are in good
condition and are sharp. Press the food down
loosely with less force.
FAULT: The cutting tool cannot be removed.
REMEDY: Always use the ejector plate. Use a
thick leather glove or other glove that the knives
of the cutting tool cannot cut through, and turn
the cutting tool clockwise to release it.
FAULT: The decoring device cannot be
removed.
REMEDY: Use the wrench to unscrew the
decoring device clockwise.

TECHNICAL SPECIFICATION

HALLDE RG - 200
MACHINE: Motor: 0.25 kW, 230 V, single-
phase, 50 Hz, with thermal motor protection.
Transmission: gears. Safety system: Two
safety switches. Degree of protection: IP44.
Power supply socket: Earthed, single-phase,
10 A. Fuse in fuse box for the premises: 10 A,
delayed. Sound level LpA (EN31201): 73 dBA.
TOOLS: Diameter: 185 mm. Speed: 350 rpm.
NET WEIGHTS: Machine: 18 kg. Cutting tools:
About 0.5 kg on average.
NORMS/STANDARDS: NSF STANDARD 8,
see declaration of conformity.
