Hardware Specifications - SMC Networks WAP3110-L Quick Start Manual

Quick Start Guide

Hardware Specifications

Item
Chassis Specifications
Size
Weight
Temperature
Humidity
Network Interfaces
Ports
2.4GHz Radio
Radio Frequencies
Power Supply Specifications
PoE Input Power
AC Power Adapter
Power Consumption
Regulatory Compliances
Radio
Emissions
Immunity
Safety
Specification
W x D x H: 140 x 140 x 47.8 mm (5.51 x 5.51 x 1.88 inches)
500 g (1.10 lbs)
Operating: 0 °C to 40 °C (32 °F to 104 °F)
Storage: -20 °C to 70 °C (-4 °F to 158 °F)
Operating: 5% to 95% (non-condensing)
One RJ-45 Port: 1000BASE-T, PoE (PD)
IEEE 802.11b/g/n
2400 ~ 2483.5 MHz
2412 ~ 2472 MHz
48 VDC, 0.3A
AC Input: 100 ~ 240 VAC
DC Output: 12 VDC, 2 A
22.5 W maximum
ETSI 300 328 (802.11b/g)
ETSI 301 893 (802.11a Full range)
ETSI 301 489 (DC power)
FCC Part 15C 15.247/15.207 (2.4-2.4835GHz)
NCC LP0002 (2.4-2.4835GHz)
EN 55022:2007, Class A/B
IEC 61000-3-2/3
FCC Class B Part 15
CNS13438
EN 55024:2001 + A2:2003
IEC 61000-4-2/3/4/5/6/8/11
CSA c us (CSA/UL60950-1)
CB (IEC60950-1)
– 6 –
