Quick Start Guide
1. Unpack the AP
2. Mount the AP
responsible for compliance with local regulations concerning items such as
antenna power, use of lightning arrestors, grounding, and radio mast or tower
construction. Therefore, it is recommended to consult a professional contractor
knowledgeable in local radio regulations prior to equipment installation.
Follow these steps to install the AP:
Unpack the AP and check the package contents.
◆
WAP3110-L Enterprise Access Point
◆
AC Power adapter
◆
Console cable (RJ-45 to DB-9)
◆
Quick Start Guide (this guide)
◆
Regulatory and Safety Information
◆
Documentation CD — includes Installation Guide
After planning your installation, mount the unit on a wall or suspended ceiling
T-rail.
1
Mounting on a Wall
.
1
Set two screws in the wall 6.2 mm (2.4 in.) apart.
2
Slide the AP's wall mounting slots down onto the screws so that the unit is secure.
2
